| 1. |
87608707
|
[1] |
CONVERSION KIT
|
NH
Twine, Includes: Ref. 2 - 96 & Instructions
|
| 2. |
86729078
|
[1] |
ROD
|
NH
Superseded by part number: 87655471
|
| 3. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Twine Knife
|
| 4. |
86620402
|
[1] |
BRACKET
|
NH
Superseded by part number: 87023416
|
| 5. |
86559592
|
[1] |
SPRING,Extension, 0.99" OD x 6-1/4" L
|
NH
Extension
|
| 6. |
86636790
|
[1] |
PLATE
|
NH
|
| 7. |
9848747
|
[2] |
SPACER
|
NH
Superseded by part number: 87023417
|
| 8. |
87048450
|
[2] |
SPRING
|
PA
3" Lg.
|
| 9. |
86979126
|
[1] |
SPACER,30.2mm ID x 41.53mm OD x 74mm L
|
PA
|
| 12. |
86553579
|
[1] |
GUIDE
|
NH
Follower, Cam
|
| 13. |
86615423
|
[1] |
SUPPORT
|
NH
Superseded by part number: 87023415
|
| 14. |
86631123
|
[1] |
SPACER,12.95mm ID x 19.05mm OD x 27mm L
|
NH
|
| 15. |
614445
|
[1] |
SPHERICAL BEARING,12.764 mm ID x 33.34 mm OD x 15.88 mm
|
NH
End, Spherical Bearing, RH-Thread
|
| 16. |
86900021
|
[1] |
TUBE,21.30 mm OD x 460.80 mm L
|
NH
Superseded by part number: 87023412
|
| 17. |
618883
|
[1] |
BALL JOINT HEAD,1/2" - 20
|
NH
End, Spherical Bearing, LH-Thread
|
| 21. |
87014413
|
[1] |
TUBE,4.80 mm OD x 1850 mm L
|
PA
|
| 22. |
86636646
|
[1] |
ROD
|
NH
|
| 47. |
165109
|
[3] |
DECAL
|
NH
Lube Fitting
|
| 53. |
9706693
|
[1] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 54. |
86508581
|
[1] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
| 58. |
9804261
|
[3] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 59. |
9804264
|
[2] |
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
|
NH
Superseded by part number: 16587625
|
| 60. |
86977727
|
[1] |
FLANGE BOLT,Hex, M12 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 64. |
328754
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 67. |
65319
|
[4] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 68. |
58225
|
[2] |
WASHER,10.32mm ID x 31.8mm OD x 3.45mm Thk
|
NH
Special, 1-1/4" OD Superseded by part number: 87654824
|
| 69. |
673
|
[1] |
WASHER,29mm ID x 41mm OD x 1.52mm Thk
|
NH
|
| 72. |
80702
|
[8] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 73. |
87364
|
[3] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
NH
|
| 76. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 77. |
140045
|
[10] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 78. |
140046
|
[14] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 81. |
88058
|
[1] |
NUT
|
NH
G2, LH Thread, 1/2"-20
|
| 82. |
9628503
|
[4] |
NUT,3/8"-16, G5
|
NH
|
| 83. |
280963
|
[1] |
NUT,Nut, 1/2-20 GR 5 ZND
|
NH
|
| 85. |
9804277
|
[7] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 87. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 88. |
86512497
|
[1] |
FLANGE NUT,M12 x 1.75, Cl 10
|
NH
|
| 89. |
88902
|
[2] |
NUT,3/8"-16
|
NH
|
| 90. |
88871
|
[1] |
NUT,1/2"-13, GC
|
NH
Superseded by part number: 86992215
|
| 93. |
100038
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 95. |
80756
|
[2] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 96. |
87395
|
[1] |
COTTER PIN,1/8" OD x 1-1/4" OAL
|
NH
|
| 100. |
87656817
|
[1] |
ANGLE
|
NH
Superseded by part number: 84283202
|
| 101. |
87656819
|
[1] |
ANGLE
|
NH
Superseded by part number: 84283199
|
| 102. |
48564
|
[2] |
90 ELBOW,90 Degree, 11/16" x 5/8", 1/8" NPT
|
NH
|
