凯斯零件查询(RBX462) - CASE IH ROUND BALER (1/03-7/05) (18.25) - MAIN CAB HARNESS KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
229 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87023029
|
[1] |
DIA KIT, HARVESTER
|
PA
Main Cab Harness, Includes: Installation Instructions
|
| 2. |
9861362
|
[1] |
POWER SOCKET
|
NH
18 Pin
|
| 3. |
492-11025
|
[1] |
LOCK WASHER,1/4"
|
CAS
Superseded by part number: 72187247, 80682
|
| 4. |
86605661
|
[1] |
SWITCH
|
NH
Remote Override
|
| 5. |
87010118
|
[1] |
WIRE HARNESS
|
NH
Tractor
|
| 6. |
787868
|
[1] |
BRACKET
|
NH
|
| 7. |
9706703
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 8. |
9706732
|
[1] |
CLAMP,19mm ID, 8.7mm Bolt Hole, P Type
|
NH
Superseded by part number: 86637976
|
| 9. |
825-2406
|
[1] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 10. |
636665
|
[1] |
LOCK WASHER,43.18mm ID x 52.68mm OD x 1.57mm Thk
|
NH
Superseded by part number: 84607513
|
| 11. |
636666
|
[1] |
NUT,1 11/16"-18
|
NH
Superseded by part number: 459329C1
|
| 12. |
767456
|
[1] |
PLUG
|
NH
Dust Superseded by part number: 87716289
|
| 13. |
617887
|
[1] |
HOOK
|
NH
S
|
| 14. |
9622758
|
[1] |
COUPLING RING
|
NH
|
| 15. |
9602128
|
[1] |
KIT
|
ZED
Contacts Superseded by part number: 900364, 900363
|
| 16. |
850072
|
[1] |
COLLAR CLAMP
|
NH
Superseded by part number: 445525
|
| 17. |
9602122
|
[1] |
KIT
|
ZED
Connector Superseded by part number: 9609191, 9609190
|
