凯斯零件查询(RBX462) - CASE IH ROUND BALER (1/03-7/05) (18.32) - RATCHET CLUTCH KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
285 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87047644
|
[1] |
DIA KIT, HARVESTER
|
PA
Ratchet Clutch, Includes: Installation Instructions
|
| 2. |
86626477
|
[1] |
SPROCKET,29T / 39T
|
NH
Double, 29T / 39T Superseded by part number: 87047645
|
| 3. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Jaw Clutch
|
| 4. |
87041658
|
[1] |
OPEN END WRENCH
|
PA
Superseded by part number: 87050935
|
| 5. |
87602188
|
[1] |
SPROCKET
|
NH
17T
|
| 6. |
86636654
|
[1] |
ARM
|
NH
|
| 7. |
87040968
|
[1] |
BUSHING
|
PA
.752" ID x .875" OD x .750" Lg. Superseded by part number: 86573067
|
| 8. |
86627870
|
[1] |
DRIVEN SPROCKET,15T
|
NH
15T Idler
|
| 9. |
86705271
|
[1] |
SPACER,13.5mm ID x 25.4mm OD x 34mm L
|
NH
|
| 10. |
814-12080
|
[1] |
BOLT,Hex, M12 x 1.75 x 80mm, Cl 8.8
|
CAS
Superseded by part number: 43158
|
| 11. |
814-12060
|
[1] |
BOLT,Hex, M12 x 1.75 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 9706693
|
| 12. |
300483
|
[1] |
SET SCREW,M10 x 25mm
|
PA
|
| 13. |
495-11053
|
[1] |
WASHER,1/2", SAE
|
CAS
Superseded by part number: 87364, 72187259
|
| 14. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 15. |
825-1412
|
[1] |
NUT,M12, Cl 8
|
CAS
Superseded by part number: 9706685
|
| 16. |
825-1410
|
[1] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 17. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 18. |
245531
|
[1] |
WASHER,25.53mm ID x 31.24mm OD x 1.65mm Thk
|
NH
|
| 19. |
58225
|
[1] |
WASHER,10.32mm ID x 31.8mm OD x 3.45mm Thk
|
NH
Superseded by part number: 87654824
|
| 20. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 21. |
36686
|
[1] |
SPACER
|
GI
Superseded by part number: 87654833
|
