| 1. |
86900310
|
[1] |
DIA KIT, HARVESTER
|
PA
Declutch, Includes: Ref. 2 - 56 & Installation Instructions Superseded by part number: 87347884
|
| 2. |
134463
|
[2] |
WASHER,.030" Thk
|
NH
|
| 3. |
768703
|
[2] |
BUSHING,10.31mm ID x 15.88mm OD x 11.13mm L
|
NH
|
| 4. |
86636884
|
[1] |
BAR
|
NH
|
| 5. |
86636886
|
[1] |
BAR
|
NH
|
| 6. |
86636763
|
[3] |
HUB
|
NH
|
| 7. |
9617629
|
[1] |
CHAIN,41 Links x 12.7mm Pitch = 520.7mm L
|
NH
ISO 1275, Riveted-Type, 41 Pitches, Includes: (2) Connector, 40 ASA Superseded by part number: 569088R91X, 242-138
|
| 8. |
87020601
|
[1] |
CHANNEL
|
PA
|
| 9. |
103243
|
[1] |
DRIVEN SPROCKET
|
NH
|
| 10. |
86636890
|
[4] |
SPACER
|
NH
|
| 11. |
86617019
|
[4] |
CAM FOLLOWER
|
NH
Cam Follower
|
| 12. |
86636981
|
[1] |
FORK
|
NH
Superseded by part number: 84148598
|
| 13. |
86636785
|
[2] |
ANGLE
|
NH
|
| 14. |
86636784
|
[2] |
BAR
|
NH
|
| 15. |
86636889
|
[1] |
SHIM
|
NH
|
| 16. |
86636874
|
[2] |
BAR
|
NH
|
| 17. |
86636660
|
[1] |
TUBE,0.75" OD x 4.50" L
|
NH
|
| 18. |
87020603
|
[1] |
CRANK
|
PA
|
| 20. |
86559592
|
[2] |
SPRING,Extension, 0.99" OD x 6-1/4" L
|
NH
Extension
|
| 21. |
86636797
|
[1] |
ANGLE
|
NH
|
| 22. |
86636875
|
[1] |
BRACKET
|
NH
|
| 23. |
9803024
|
[1] |
CHAIN
|
NH
Superseded by part number: 89803024
|
| 24. |
86636998
|
[1] |
BLOCK
|
NH
|
| 25. |
26312
|
[1] |
WASHER
|
NH
Superseded by part number: 695335
|
| 26. |
87020602
|
[1] |
PLATE
|
PA
|
| 27. |
86636724
|
[1] |
IDLER,101.6mm Idler Dia x 115.49mm OD x 37.31mm W
|
NH
|
| 30. |
814-10140
|
[1] |
BOLT,Hex, M10 x 1.5 x 140mm, Cl 8.8
|
CAS
Superseded by part number: 331168
|
| 31. |
844-10030
|
[1] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 32. |
844-10040
|
[1] |
BOLT,Hvy Hex, M10 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 9804263, 87778247
|
| 33. |
844-12060
|
[1] |
BOLT,Hvy Hex, M12 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 9804270
|
| 35. |
811-10030
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 36. |
811-10040
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 374892
|
| 37. |
811-10050
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 350459
|
| 38. |
811-12030
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 120044
|
| 39. |
280667
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 5/8" - 11 x 2 1/4", Gr 5
|
NH
|
| 42. |
86511323
|
[5] |
WASHER,10.5mm ID x 20mm OD x 2mm Thk
|
NH
Superseded by part number: 14496621
|
| 43. |
86511324
|
[1] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 44. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
Superseded by part number: 86729275
|
| 45. |
140045
|
[20] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 46. |
140046
|
[3] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 49. |
825-2410
|
[23] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 50. |
9804279
|
[3] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 52. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 53. |
280474
|
[4] |
NUT,7/16"-20, GC
|
NH
|
| 55. |
219-87
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 56. |
432-1224
|
[1] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
Superseded by part number: 80754
|
| 57. |
9828102
|
[1] |
CONNECTING LINK
|
NH
Superseded by part number: 86595261
|
