斗山零件查询MAIN PIPING(3) - ARM & BUCKET DX490LC-5(S/N:10001~10011) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
779 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-08059
|
[-] |
|
|
| 101. |
2181-1950D1
|
[2] |
PLUG
|
|
| 102. |
S8000111
|
[2] |
O-RING
|
|
| 17. |
DS20401018
|
[1] |
|
|
| 18. |
DS20401024
|
[1] |
|
|
| 25. |
DS20401042
|
[1] |
|
|
| 26. |
DS20401043
|
[1] |
|
|
| 40. |
2181-9086
|
[6] |
FLANGE;SPLIT
|
|
| 41. |
K1014858
|
[2] |
FLANGE;SPLIT
|
|
| 54. |
S2218566
|
[12] |
BOLT;SOCKET
|
|
| 57. |
S2219166
|
[4] |
BOLT;SOCKET M14X2.0X75
|
|
| 6. |
100201-00068C
|
[1] |
|
|
| 67. |
2180-1026D23
|
[7] |
O-RING
|
|
| 68. |
2180-1026D28
|
[2] |
O-RING
|
|
