| 1. |
177822
|
[2] |
SPACER,8.33mm ID x 12.7mm OD x 4.32mm Thk
|
NH
21/64" ID x .500" OD x .170" Lg.
|
| 2. |
84176297
|
[1] |
ANGLE
|
NH
|
| 3. |
86977396
|
[1] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
PA
|
| 4. |
84226853
|
[1] |
KIT
|
NH
Relay Conversion
|
| 5. |
529070
|
[7] |
CABLE TIE,368.3mm L
|
NH
CABLE STRAP
|
| 6. |
86618546
|
[2] |
SUPPORT
|
NH
|
| 7. |
263117
|
[18] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 8. |
86622152
|
[1] |
WIRE HARNESS
|
NH
Main Superseded by part number: 86508603, 84214838
|
| 9. |
264795
|
[4] |
ELECTRIC INSULATION
|
NH
|
| 10. |
86629248
|
[1] |
ECU
|
NH
Includes: Ref. 39 Superseded by part number: 87035276
|
| 10. |
87035276R
|
[1] |
REMAN ELECT CONTROL
|
BRR
ECU - Bale Slice & Rotor Cutter
|
| 10. |
87035276C
|
[1] |
CORE-ELECTRONIC CONT
|
BRR
ECU - Bale Slice & Rotor Cutter
|
| 11. |
86628564
|
[2] |
CLAMP,31.7mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
Superseded by part number: 515-23317
|
| 12. |
86611813
|
[1] |
ANGLE
|
PA
|
| 13. |
86594422
|
[1] |
SENSOR
|
NH
|
| 14. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
Switch, Nylon
|
| 15. |
9612631
|
[1] |
COVER
|
NH
|
| 17. |
86643172
|
[1] |
ASSEMBLY
|
NH
Pivot Mount Superseded by part number: 87034842
|
| 18. |
86614361
|
[1] |
ARM
|
NH
|
| 19. |
515-2279
|
[1] |
CLAMP,5/16", Insul, 5/16" Bolt
|
CAS
Superseded by part number: 853764
|
| 20. |
86617869
|
[1] |
LINK
|
NH
|
| 21. |
86613601
|
[1] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk
|
NH
Urethane
|
| 22. |
173011
|
[2] |
GROMMET,1” ID x 1.750” OD x .500” Tk
|
NH
1-3/4" OD x 1" ID
|
| 23. |
844-6030
|
[1] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86511839
|
| 24. |
10445221
|
[2] |
SCREW,Hex, M4 x 25mm, Cl 8.8
|
MKT
|
| 25. |
87310126
|
[2] |
SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST
|
BUR
Pan HD, Stainless Steel, #10-24 x 3/4"
|
| 26. |
844-6016
|
[2] |
BOLT,Hvy Hex, M6 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 9804255
|
| 27. |
844-8020
|
[6] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 29. |
825-2408
|
[4] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 30. |
825-1406
|
[8] |
NUT,M6, Cl 8
|
CAS
Superseded by part number: 86500688
|
| 31. |
231-5144
|
[8] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 32. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
Lock, Washer Hd, Stainless, #10-24
|
| 33. |
825-2406
|
[2] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 34. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 35. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 36. |
493-41020
|
[2] |
LOCK WASHER,Ext Tooth, #10
|
CAS
Superseded by part number: 9672521
|
| 37. |
495-21038
|
[2] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 38. |
811-6016
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 86512439
|
| 39. |
86529089
|
[1] |
RELAY
|
NH
|
| 41. |
86010402
|
[1] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 42. |
412327
|
[2] |
CARRIAGE BOLT,Short Sq Nk, M6 x 1 x 40mm, Full Thd, Cl 8.8
|
NH
|
| 43. |
792026
|
[1] |
LOCKING RING,1.06" ID x 1.25" OD x 0.13" Thk
|
NH
Split, Int, 1.00"
|
| 44. |
788614
|
[1] |
PROTECTING COVER
|
NH
|
