神钢零件查询(F4GE9684E J615) - ENGINE 5801763602 - 47613194 (8/14-) (10.102.AP) - ENGINE OIL PAN Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
904 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852308 | [1] | ENGINE OIL PAN | TOR Superseded by part number: 500388254 |
| 2. | 4894139 | [1] | PLUG,Hex Soc, M22 x 1.5 | TOR |
| 5. | 4897858 | [1] | SPACER | TOR |
| 6. | 4897861 | [1] | OIL PAN GASKET SET,17.3mm Thk | TOR |
| 7. | 2852654 | [1] | SUCTION PIPE | TOR Superseded by part number: 504082951 |
| 8. | 4895291 | [3] | SCREW,Hex Flg, M10 x 1.5 x 20 | TOR |
| 9. | 4898301 | [1] | GASKET,0.42mm Thk | TOR |
| 10. | 504271972 | [1] | HYD CONNECTOR | BHB |
| 11. | 16690577 | [2] | SCREW,Skt Hd, M8 x 1.25 x 20mm | ZED |
| 12. | 14463881 | [1] | O-RING,1.359" ID x 0.139" Width | IMO Superseded by part number: 17289281 |
| 13. | 2852663 | [1] | CLAMP | TOR Superseded by part number: 504047521 |
| 14. | 4899068 | [1] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 15. | 17044735 | [1] | NUT,Hex, M8 | TOR |
| 16. | 504084873 | [1] | SUPPORT | BHB |
| 17. | 2853363 | [1] | DRAIN | TOR Superseded by part number: 504040826 |
| 18. | 504040843 | [1] | LINE | LINE |
