神钢零件查询(F4GE9684G J601) - ENGINE - 504375341 - 84250441 (7/13-) (10.103.AK) - FLYWHEEL & HOUSING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
735 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899026 | [2] | DOWEL,M18 x 10 | TOR |
| 2. | 4899109 | [2] | SCREW,Hex, M10 x 1.5 x 80 | BASM10 x 1.5 x 80 |
| 2. | 4892915 | [11] | FLANGE BOLT,Hex, M10 x 1.5 x 40mm | TORM10 x 1.5 x 40 |
| 2. | 4899076 | [5] | SCREW,Hex Flg, M12 x 1.75 x 80 | TORM12 x 1.75 x 80 |
| 2. | 4899074 | [3] | SCREW,Hex Flg, M12 x 1.75 x 120 | TORM12 x 1.75 x 120 |
| 3. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TORM18 x 1.25 x 20 Superseded by part number: 16673635 |
| 4. | 4895378 | [1] | BUTTON PLUG,M29.2 | TOR |
| 5. | 4895379 | [1] | O-RING,21.82mm ID x 3.53mm Width | TORID = 21.82 x 3.53 Superseded by part number: 17288480 |
| 6. | 2854073 | [1] | COVER | TORASSY, Incl 7, 8 Superseded by part number: 504115364 |
| 7. | NSS | [2] | NOT SOLD SEPARAT | CONCover, Incl in 6 |
| 8. | 2854075 | [1] | O-RING,0.103" Thk x 2.987" ID, -151 | TORID = 75.87 x 2.62 |
| 10. | 4895155 | [1] | COVER | TOR |
| 11. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BASM8 x 1.25 x 16 |
