凯斯零件查询(RBX463) - CASE IH ROUND BALER (9/05-12/06) (11.41) - WHEELS, HUB & SPINDLE, HEAVY DUTY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
966 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86631642
|
[1] |
HUB
|
NH
& Spindle, Heavy Duty
|
| 2. |
87022911
|
[1] |
OIL SEAL
|
PA
Oil
|
| 3. |
26799990
|
[1] |
TAPERED BEARING,55mm ID x 120mm OD x 45.5mm W
|
TTF
|
| 4. |
87018138
|
[1] |
HUB
|
PA
|
| 5. |
84021877
|
[1] |
TAPERED BEARING,50mm ID x 80mm OD x 20mm W
|
ZED
Superseded by part number: 87281696
|
| 6. |
87022923
|
[1] |
SLOTTED NUT
|
PA
Slotted, M39 x 1.5
|
| 7. |
432-1032
|
[1] |
COTTER PIN,5/32" x 2"
|
CAS
Superseded by part number: 86523957
|
| 8. |
87022925
|
[1] |
CAP
|
PA
HUB
|
| 9. |
87018139
|
[6] |
BOLT
|
PA
Wheel, M18 x 1.5
|
| 10. |
86625632
|
[6] |
WHEEL NUT,Hex, M18 x 1.5
|
NH
Wheel, M18 x 1.5
|
| 11. |
87018137
|
[1] |
SPINDLE,368mm L
|
PA
|
| 12. |
87036687
|
[1] |
SHIELD
|
PA
Grease, M80 OD
|
| 13. |
87036688
|
[1] |
SHIELD
|
PA
Grease, M100 OD
|
