神钢零件查询(F4GE9684G J601) - ENGINE - 504375341 - 84250441 (7/13-) (10.250.AE) - TURBOCHARGER, RETURN LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
136 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899079 | [2] | SCREW,Hex Flg, M8 x 1.25 x 25 | TORM8 x 1.25 x 25 |
| 2. | 2852134 | [1] | FLANGE BOLT,Hex, M12 x 1.75 x 25mm | TORM12 x 1.75 x 25 Superseded by part number: 16677735 |
| 3. | 2852919 | [1] | RIGID TUBE | TORASSY, Incl 4, 5 Superseded by part number: |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Incl in 3 |
| 5. | 4899058 | [2] | O-RING,0.674" ID x 0.88" OD x 0.103" | TOR Superseded by part number: 17281881 |
| 6. | 4899827 | [1] | SUPPORT | SM |
| 7. | 4891288 | [1] | GASKET,0.8mm Thk | TOR |
