| 1. |
21517500
|
[1] |
Flywheel
|
|
| 2. |
21517489
|
[1] |
Gear ring
|
|
| 3. |
9454743
|
[10] |
Screw
|
|
| 4. |
31401209
|
[5] |
Connecting rod
|
|
| 5. |
|
|
|
|
| 6. |
|
|
|
|
| 7. |
9497858
|
[2] |
Screw
|
|
| 8. |
31251996
|
[5] |
Big-end bearing kit
|
|
| 9. |
31330321
|
[5] |
Main bearing
|
Red, Without flange, upper, See workshop Manual
|
| 10. |
30777951
|
[5] |
Main bearing
|
Red, Without flange, lower, See workshop Manual
|
| 11. |
31330322
|
[5] |
Main bearing
|
Yellow, Without flange, upper, See workshop Manual
|
| 12. |
30777952
|
[5] |
Main bearing
|
Yellow, Without flange, lower, See workshop Manual
|
| 13. |
31330323
|
[5] |
Main bearing
|
Blue, Without flange, upper, See workshop Manual
|
| 14. |
30777953
|
[5] |
Main bearing
|
Blue, Without flange, lower, See workshop Manual
|
| 15. |
31330324
|
[5] |
Main bearing
|
Green, Without flange, upper, See workshop Manual
|
| 16. |
30777954
|
[5] |
Main bearing
|
Green, Without flange, lower, See workshop Manual
|
| 17. |
31316541
|
[1] |
Flange bearing
|
Red, With flange, upper, See workshop Manual
|
| 18. |
31316551
|
[1] |
Flange bearing
|
Red, With flange, lower, See workshop Manual
|
| 19. |
31316542
|
[1] |
Flange bearing
|
Yellow, With flange, upper, See workshop Manual
|
| 20. |
31316552
|
[1] |
Flange bearing
|
Yellow, With flange, lower, See workshop Manual
|
| 21. |
31316543
|
[1] |
Flange bearing
|
Blue, With flange, upper, See workshop Manual
|
| 22. |
31316553
|
[1] |
Flange bearing
|
Blue, With flange, lower, See workshop Manual
|
| 23. |
973660
|
[1] |
Spring pin
|
|
| 24. |
31375826
|
[1] |
Crankshaft
|
|
| 25. |
30777171
|
[1] |
Pulley
|
|
| 26. |
31258122
|
[1] |
Oscillation damper
|
|
| 27. |
984755
|
[4] |
Flange screw
|
|
| 28. |
3531111
|
[1] |
Nut
|
|
| 29. |
31339777
|
[5] |
Piston kit
|
Class C
|
| 29. |
31339778
|
[5] |
Piston kit
|
Class D
|
| 29. |
31339779
|
[5] |
Piston kit
|
Class E
|
| 30. |
30777225
|
[10] |
Lock ring
|
|
| 31. |
|
|
|
|
| 32. |
31339782
|
[5] |
Piston ring kit
|
|
| 33. |
21373176
|
[1] |
Flexible coupling
|
|
| 34. |
828250
|
[1] |
Lubricating grease
|
|
| 35. |
946671
|
[6] |
Flange screw
|
|
| 36. |
21255747
|
[1] |
Vibration damper
|
|
| 37. |
1161325
|
[1] |
Silicone grease
|
See Workshop Manual
|
