现代零件查询R110-7 MAIN CONTROL VALVE(4/4,2-BLOCK,#650-939)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
222 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 18. |
XKBF-00921
|
[5] |
PLUG
|
|
| 19. |
XKBF-00889
|
[5] |
POPPET 1
|
|
| 20. |
XKBF-00890
|
[5] |
SPRING
|
|
| 21. |
XKBF-00934
|
[4] |
PLUG
|
|
| 22. |
XKBF-00893
|
[3] |
POPPET 2
|
|
| 23. |
XKBF-00894
|
[3] |
SPRING
|
|
| 25. |
XKBF-00486
|
[2] |
RELIEF VALVE-OVERLOAD
|
|
| 26. |
XKBF-00487
|
[6] |
PLUG
|
|
| 55. |
XKBF-00399
|
[1] |
ORIFICE-SIGNAL
|
|
| 56. |
XKBF-00922
|
[1] |
FILTER-COIN TYPE
|
|
| 58. |
XKBF-00488
|
[2] |
PLUG
|
|
| 59. |
XKBF-00923
|
[1] |
PLUG
|
|
| 70. |
XKBF-00932
|
[5] |
PLUG
|
|
| 72. |
XKBF-00933
|
[2] |
PLUG
|
|
| 77. |
XKBF-00958
|
[3] |
O-RING
|
|
| 80. |
XKBF-00940
|
[1] |
O-RING
|
|
| 81. |
XKBF-00941
|
[7] |
O-RING
|
|
| 83. |
XKBF-00942
|
[5] |
O-RING
|
|
| 84. |
XKBF-00943
|
[5] |
O-RING
|
|
| 87. |
XKBF-00962
|
[2] |
RING-BACK UP
|
|
