现代零件查询R110-7 MAIN CONTROL VALVE(4/4, 2-BLOCK, #0940-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
875 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 17. |
XKCG-00506
|
[2] |
OVERLOAD RELIEF V/V(STD)
|
|
| 28. |
XKCG-00447
|
[6] |
PLUG
|
|
| 29. |
XKCG-00263
|
[2] |
PLUG
|
|
| 31. |
XKCG-00052
|
[2] |
PLUG
|
|
| 32. |
XKCG-00514
|
[5] |
PLUG(PF 3/4)
|
|
| 34. |
XKCG-00515
|
[3] |
PLUG(PARALLEL, PF 1/2)
|
|
| 36. |
XKCG-00516
|
[6] |
PLUG(RELIEF CAT M27X1.5)
|
|
| 43. |
XKCG-00520
|
[6] |
POPPET-LOAD CHECK D20
|
|
| 44. |
XKCG-00521
|
[1] |
POPPET-LOAD CHECK D16
|
|
| 48. |
XKCG-00043
|
[1] |
ORIFICE-SIGNAL
|
|
| 49. |
XKCG-00044
|
[1] |
FILTER-COIN TYPE
|
|
| 62. |
XKCG-00059
|
[2] |
O-RING
|
|
| 63. |
XKCG-00257
|
[3] |
O-RING
|
|
| 64. |
XKCG-00461
|
[6] |
O-RING
|
|
| 65. |
XKCG-00060
|
[7] |
O-RING
|
|
| 67. |
XKCG-00528
|
[5] |
O-RING 1B P24
|
|
| 70. |
XKCG-00530
|
[4] |
O-RING AS568 008
|
|
| 72. |
XKCG-00065
|
[6] |
O-RING
|
|
| 73. |
XKCG-00066
|
[4] |
O-RING
|
|
| 77. |
XKCG-00070
|
[6] |
RING-BACK UP
|
|
| 78. |
XKCG-00463
|
[6] |
RING-BACK UP
|
|
| 79. |
XKCG-00535
|
[6] |
SPRING-LOAD CHECK D20
|
|
| 80. |
XKCG-00536
|
[1] |
SPRING-LOAD CHECK D16
|
|
