| 1. |
86626594
|
[1] |
ROLL
|
NH
Backwrap, Steel
|
| 1. |
86635361
|
[1] |
ROLLER
|
PA
Backwrap, Rubber
|
| 2. |
86590751
|
[2] |
BEARING ASSY,40mm ID
|
NH
Includes: Ref. 23 Superseded by part number: 87660576
|
| 3. |
9848759
|
[1] |
BELT,127.00 mm W x 1520.00 mm L
|
NH
Trash Baffle
|
| 4. |
86548820
|
[1] |
BELT,178.00 mm W x 1520.00 mm L
|
NH
Trash Baffle
|
| 5. |
86637011
|
[1] |
CHANNEL
|
NH
Superseded by part number: 87048815
|
| 6. |
86636769
|
[1] |
SCRAPER BLADE
|
NH
|
| 7. |
86557580
|
[1] |
ROLLER
|
NH
Sledge Follower, Includes: Ref. 22
|
| 8. |
86553395
|
[2] |
SUPPORT
|
NH
|
| 9. |
87030468
|
[2] |
HUB
|
PA
Superseded by part number: 87398962
|
| 12. |
614-8030
|
[10] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 13. |
614-10030
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 14. |
827-12045
|
[2] |
BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd
|
CAS
Superseded by part number: 86639031
|
| 15. |
614-12040
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 16. |
280519
|
[10] |
SELF-TAP SCREW,Hex, 5/16" - 12 x 1"
|
NH
|
| 19. |
322
|
[20] |
WASHER,8.73mm ID x 42.07mm OD x 3.43mm Thk
|
NH
Special
|
| 20. |
322358
|
[10] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 21. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 22. |
86553396
|
[2] |
BEARING ASSY,30.23mm ID x 90mm OD x 30.2mm W, SQUARE BORE
|
NH
Includes: Ref. 24
|
| 23. |
563733
|
[2] |
COLLAR
|
ZED
Lock
|
| 24. |
86548282
|
[2] |
BALL BEARING,29.41mm ID x 90mm OD x 30.2mm W, Square Bore
|
NH
|
