| 1. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 2. |
86599042
|
[1] |
ROLLER
|
NH
Drive Superseded by part number: 84467975
|
| 3. |
86600450
|
[1] |
ROLLER
|
NH
Floor, Includes: Round Rods
|
| 4. |
86628106
|
[2] |
SHIELD
|
NH
|
| 5. |
86615686
|
[1] |
ROLL
|
NH
Fixed, Includes: Round Rods Superseded by part number: 87602845, 84478246
|
| 6. |
86615691
|
[1] |
SHAFT
|
NH
|
| 7. |
86636760
|
[2] |
RING
|
NH
|
| 8. |
86978595
|
[1] |
BEARING ASSY
|
PA
Endless Belt
|
| 9. |
86590753
|
[2] |
BEARING ASSY
|
NH
|
| 10. |
86624773
|
[1] |
ROLL
|
NH
Starter, Includes: Round Rods Superseded by part number: 87554101
|
| 11. |
86837676
|
[4] |
FLANGED BEARING
|
PA
Superseded by part number: 86979948
|
| 12. |
286909
|
[2] |
BALL BEARING,38.11mm Hex x 84.99mm OD x 30mm W
|
NH
Superseded by part number: 47577178
|
| 13. |
86610638
|
[2] |
BEARING ASSY,45mm ID
|
NH
|
| 14. |
86622263
|
[2] |
HUB
|
NH
Superseded by part number: 87660304
|
| 15. |
86619043
|
[1] |
WASHER,45.2mm ID x 60.3mm OD x 3.68mm Thk
|
NH
Plated
|
| 17. |
274247
|
[8] |
BOLT,Hex Flg, M10 x 16mm, Stainless
|
NH
|
| 18. |
614-12035
|
[20] |
BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd
|
IH
|
| 19. |
614-16040
|
[8] |
BOLT,Hex, M16 x 2 x 40mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 86509867
|
| 20. |
814-12050
|
[8] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 9706702
|
| 21. |
614-12040
|
[2] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 22. |
58821
|
[1] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
Special
|
| 23. |
238113
|
[1] |
WASHER
|
NH
1.8" ID x .036" Thk Superseded by part number: 87017559
|
| 25. |
140046
|
[28] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 26. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 29. |
9804279
|
[8] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 31. |
219-417
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 571382
|
| 32. |
412689
|
[1] |
LOCK PIN,8mm OD x 50mm L, Slotted
|
NH
|
| 33. |
432-1232
|
[1] |
COTTER PIN,3/16" OD x 2" L
|
CAS
Superseded by part number: 87400
|
