神钢零件查询(F4HFE4135 B003) - ENGINE 5802094949 84553225 TC4.90 and TC5.70 TIER4B (10/16-) (10.304.AS) - DIPSTICK Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
827 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONTube, Incl in 1 |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONDipstick, Incl in 1 |
| 4. | 4895406 | [2] | EXPANSION PLUG,9.8mm OD | TOR |
| 5. | 4895037 | [1] | EXPANSION PLUG,32.03mm | TOR |
| 6. | 2852323 | [1] | SCREW,M8 x 1.25 x 14mm | TORM8 x 1.25 x 14mm Superseded by part number: 16597925 |
| 7. | 4897330 | [2] | HEX SOCKET PLUG,M12 x 1.5 | TOR |
| 8. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONO-ring, Incl in 1 |
