神钢零件查询(F4HFE4135 B003) - ENGINE 5802094949 84553225 TC4.90 and TC5.70 TIER4B (10/16-) (10.400.AE) - COOLING SYSTEM LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
577 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852212 | [3] | FLANGE BOLT,Hex, M8 x 1.25 x 25mm | TOR |
| 2. | 2854072 | [2] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONSupport, incl in 3 |
| 5. | 98405182 | [2] | DOWEL | TOR |
| 6. | 4895393 | [1] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 7. | 4895080 | [1] | HEX SOCKET PLUG,M22 x 1.5 | TORASSY, Incl 8, 9 |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 7 |
| 9. | 4895082 | [1] | O-RING,19.3mm ID x 2.2mm Width | TOR Superseded by part number: 2854072 |
| 11. | 4895078 | [2] | PIPE PLUG,1/2"-14 | TOR |
| 13. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORASSY, Incl 14, 15 |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 13 |
| 15. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
| 16. | 4893036 | [2] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 17. | 4895392 | [1] | HEX SOCKET PLUG,M18 x 1.5 | TORASSY, Incl 6, 18 |
