纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (6.711[04]) - ELECTRICAL SYSTEM - ELECTRIC WIRING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
777 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 10117201 | [1] | CLAMP | LEC3-10 |
| 2. | 76042591 | [1] | BRACKET | LEC |
| 3. | 10902331 | [1] | SCREW,Hex, M6 x 18mm, Cl 10.9, Full Thd | LEC |
| 4. | 15896221 | [1] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED Superseded by part number: 86500688 |
| 5. | 14496431 | [1] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 6. | 11103031 | [1] | BOLT,Hex, M10 x 18, 10.9, Full Thd | LEC |
| 7. | 14496631 | [1] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 8. | 16043031 | [1] | BOLT,Hex, M8 x 12mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43231 |
| 9. | 14496531 | [1] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 10. | 76052577 | [2] | ELEC CONNECTOR | LEC- SOLENOID VALVE |
| 11. | 76068106 | [3] | ELECTRIC CABLE | LEC- SOLENOID VALVE |
| 12. | 76069231 | [1] | WIRE HARNESS | LEC |
