纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (3.434[01]) - HYDRAULIC SYSTEM PIPING - VERSION (01) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
626 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76069226 | [1] | HYD. TUBE | LEC- SUCTION |
| 2. | 10118540 | [1] | PLUG,M10 x 1 x 11, Brass | LECAssy |
| 3. | 14465481 | [1] | O-RING,3.234" ID x 3.512" OD x 0.139" | LEC(M82.14 ID x 3.53 Thk) |
| 4. | 12648531 | [4] | WASHER,12.2mm ID x 28mm OD x 4mm Thk | LEC Superseded by part number: 86625256 |
| 5. | 14311031 | [4] | HEX SOC SCREW,M12 x 1.75 x 25mm, Cl 10.9, Full Thd | LEC |
| 7. | 14437585 | [1] | O-RING,8.00mm ID x 1.50mm | IMO |
| 8. | 79083849 | [4] | HOSE CLAMP,M70-90 | LEC Superseded by part number: 71404504 |
| 9. | 76069244 | [1] | HYD. TUBE | LEC |
| 10. | 14464981 | [1] | O-RING,66.27mm ID x 2.887" OD x 3.53mm | LEC(M66.27 ID x 3.53 Thk) Superseded by part number: 17290381 |
| 11. | 11112831 | [4] | SCREW,Hex, M12 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11125434 |
| 12. | 76069247 | [2] | HOSE,76.00 mm ID x 200.00 mm | LEC |
| 13. | 76069630 | [1] | HYD. TUBE | LEC- SUCTION |
| 14. | 76069256 | [3] | BRACKET | LEC |
| 15. | 11106431 | [3] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 9515003 |
| 16. | 79005244 | [3] | WASHER,10.6mm ID x 25mm OD x 6mm Thk | LEC |
