纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (3.471[01]) - PIPING - HYDRAULIC TILT - VERSION (01) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
644 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76069265 | [2] | HYD CONNECTOR | LEC |
| 2. | 78100135 | [2] | PLUG,M12 | LEC |
| 3. | 78100008 | [2] | HYD CONNECTOR | LEC |
| 4. | 76046666 | [2] | FLEXIBLE HOSE | LEC |
| 5. | 79084821 | [2] | CLAMP | LEC |
| 6. | 16040831 | [2] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43248 |
| 7. | 12638631 | [2] | WASHER,10.6mm ID x 18mm OD x 2mm Thk | LEC Superseded by part number: 86625251 |
