纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.481[01]) - HYDRAULIC TILT - ANGLEDOZER (HA) - VERSION (01-02) - OPTIONAL CODE 76054830 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
662 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76071257 | [1] | HYDRAULIC HOSE | LEC |
| 1. | 76071258 | [1] | HYDRAULIC HOSE | LEC |
| 2. | 76071276 | [1] | GUARD | LEC Superseded by part number: 76092049 |
| 3. | 76071256 | [1] | GUARD | LEC Superseded by part number: 76092050 |
| 4. | 70924922 | [2] | O-RING,-212, 90 Duro, .859" ID x .139" Thk | LEC(M21.82 ID x 3.53 Thk) |
| 5. | 14420331 | [8] | HEX SOC SCREW,M10 x 1.5 x 35mm, Cl 10.9, Full Thd | LEC |
| 6. | 16043831 | [4] | SCREW,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd | BHB Superseded by part number: |
| 7. | 14496531 | [4] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 8. | 11106231 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 9. | 14496631 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 10. | 76007732 | [4] | HALF-FLANGE | LECSAE 3/4 |
| 11. | 76068249 | [1] | CABLE | LEC |
| 12. | 76071252 | [1] | BUSHING | LEC |
| 13. | 70929699 | [1] | WASHER | LEC |
| 14. | 14496931 | [1] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: 86625266 |
| 15. | 15981131 | [1] | BOLT,Hex, M16 x 1.5 x 60mm, Cl 10.9 | LEC Superseded by part number: 15981134 |
| 16. | 15504021 | [1] | NUT,M16 x 1.5 | MKT |
| 17. | 79083845 | [3] | HOSE CLAMP,32mm - 50mm, Worm Gear | LEC Superseded by part number: 71404506 |
