纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.480[01]) - ANGLE MOLDBOARD (HA) - ANGLEDOZER (HA) - VERSION (01-02) - OPTIONAL CODE 76046824 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
988 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76046824 | [1] | DOZER BLADE | LEC- ASSY Superseded by part number: 76092005 |
| 2. | 79104464 | [1] | CUTTING EDGE | LEC- RIGHT IN ALTERNATIVE |
| 2. | 8294273 | [1] | CUTTING EDGE | LEC- RIGHT IN ALTERNATIVE |
| 3. | 79104483 | [1] | CUTTING EDGE | LEC- LEFT IN ALTERNATIVE |
| 3. | 8294274 | [1] | CUTTING EDGE | LEC- LEFT IN ALTERNATIVE |
| 4. | 8296247 | [1] | BRACKET | LEC Superseded by part number: 11422331, 80280248, 8273213 |
| 5. | 8273530 | [12] | SCREW,Sq Hd, M20 x 1.5 x 72mm | LEC20X1,5 Superseded by part number: 8289500 |
| 6. | 12164333 | [33] | NUT,M20 x 1.5, Cl 12 | LEC Superseded by part number: 86015195 |
| 7. | 14497131 | [33] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
| 8. | 16162437 | [6] | BOLT,Hex, M18 x 2.5 x 45mm, Cl 10.9, Full Thd | LEC18X2,5X45 |
| 9. | 14497031 | [6] | WASHER,M18 x 34 | LEC |
| 10. | 8294269 | [1] | CUTTING EDGE,Bolt On, Double Edged, 7 Hole, 200mm W x 1063mm L | LEC |
| 11. | 8282270 | [21] | PLOW BOLT,Plow, M20 x 1.5 x 67mm, Cl 10.9 | LEC |
| 12. | 79077486 | [2] | CUTTING EDGE | LEC |
