纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.481[03]) - HYDRAULIC TILT - ANGLEDOZER (HA) - VERSION (01-02) - OPTIONAL CODE 76054830 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
876 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76041028 | [1] | OPERATING CYLINDER | LEC- ASSY SEE PAG.4 Superseded by part number: 84278576 |
| 2. | 76033000 | [2] | SUPPORT | LEC Superseded by part number: 76092042 |
| 3. | 76033002 | [2] | PIN,40mm OD x 134mm L | LEC |
| 4. | 76032992 | [1] | ADJUSTMENT ROD | LEC Superseded by part number: 76092041 |
| 5. | 76032994 | [1] | STRUT | LEC Superseded by part number: 76092040 |
| 6. | 76033001 | [3] | PIN | LEC |
| 7. | 8297924 | [2] | FLANGE | LEC Superseded by part number: 76092043 |
| 8. | 76033003 | [1] | PIN | LEC |
| 9. | 11115531 | [6] | BOLT,Hex, M14 x 30, 10.9, Full Thd | LEC Superseded by part number: 11115534 |
| 10. | 14496831 | [6] | WASHER,15mm ID x 28mm OD x 2.5mm Thk | LEC14,4X28 |
| 11. | 11116831 | [2] | BOLT,Hex, M14 x 80, 10.9 | LEC |
| 12. | 12163221 | [4] | NUT,M14, Cl 10 | LEC Superseded by part number: 87564740 |
| 13. | 76035973 | [1] | PIN | LEC |
| 14. | 8270126 | [3] | PLATE | LEC Superseded by part number: 76092114 |
| 15. | 11117031 | [2] | BOLT,Hex, M14 x 90, 10.9 | LEC |
