纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.652[13]) - ROPS CAB - REAR WINDSHIELD WIPER - OPTIONAL CODE 76069709 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
720 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76067671 | [1] | WIPER MOTOR | LEC24V |
| 2. | 76045506 | [1] | WIPER BLADE | LECL=550 |
| 3. | 76067637 | [1] | WIPER ARM | LECL=425 |
| 4. | 10902221 | [2] | BOLT,Hex, M6 x 16mm, CL 8.8 | BHB Superseded by part number: |
| 5. | 76067742 | [2] | WASHER | LEC7X20X3 |
| 6. | 14496431 | [2] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 7. | 76067232 | [1] | BRACKET | LEC |
| 8. | 16043421 | [2] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd | TTF Superseded by part number: 16043424 |
| 9. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 10. | 76067233 | [1] | SPACER | LEC |
