纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.652[17]) - ROPS CAB - COVERING - OPTIONAL CODE 76069709 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
682 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76067328 | [1] | SOFT TRIM | LEC- UPPER |
| 2. | 76067634 | [2] | RETAINER | LEC |
| 3. | 76067478 | [1] | RETAINER | LEC- REAR UPPER |
| 4. | 79105220 | [28] | SCREW,Phillips Drive, Oval HD, M6 x 20mm | IMO |
| 5. | 76067309 | [22] | CUP WASHER | LECNylon |
| 6. | 15629711 | [13] | THREADED INSERT | BURM6 x 9.5 |
| 7. | 76067335 | [1] | GUARD | LEC- REAR WIPER |
| 8. | 76067048 | [1] | MAT | LECPVC |
| 9. | 76067049 | [1] | RETAINER | LEC- LEFT |
| 10. | 76067050 | [1] | RETAINER | LEC- RIGHT |
| 11. | 76067553 | [1] | FLOOR MAT | LEC |
| 12. | 76067492 | [1] | INSULATING PANEL | LEC |
| 13. | 76067493 | [1] | INSULATING PANEL | LEC |
| 14. | 76067494 | [1] | INSULATING PANEL | LEC- CENTRAL |
| 15. | 76067495 | [1] | INSULATING PANEL | LEC- FRONT UPPER |
| 16. | 76067533 | [1] | INSULATING PANEL | LEC- OUTER LEFT |
| 17. | 76067534 | [1] | INSULATING PANEL | LEC- OUTER RIGHT |
| 18. | 76048381 | [4] | BUTTON | LEC Superseded by part number: 1493629 |
