纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.652[18]) - ROPS CAB - COVERING - OPTIONAL CODE 76069709 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
769 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76067329 | [1] | SOFT TRIM | LEC- UPPER LEFT |
| 2. | 76067345 | [1] | ADJUSTING SLEEVE | LEC- FRONT LEFT |
| 3. | 79105220 | [16] | SCREW,Phillips Drive, Oval HD, M6 x 20mm | IMO |
| 4. | 76067309 | [20] | CUP WASHER | LEC |
| 5. | 15629711 | [16] | THREADED INSERT | BURM6 x 9.5 |
| 6. | 76067717 | [1] | SOFT TRIM | LEC- UPPER RIGHT |
| 7. | 76047274 | [8] | NUT,M6 x 1 | LEC |
| 8. | 13313217 | [8] | SCREW,Pozidriv Oval Hd, Csk, M6 x 20mm, Cl 5.8, Full Thd | LEC |
| 9. | 76067665 | [1] | SEAL | LEC |
| 10. | 76067471 | [1] | SOFT TRIM | LEC- CONTROLS |
| 11. | 76067336 | [1] | SOFT TRIM | LEC- REAR |
| 12. | 76067338 | [1] | SOFT TRIM | LEC- REAR RIGHT |
| 13. | 76067326 | [1] | INSULATING PANEL | LEC |
| 14. | 76067327 | [1] | INSULATING PANEL | LEC |
| 15. | 76067487 | [1] | INSULATING PANEL | LEC- UPPER LEFT |
| 16. | 76067488 | [1] | INSULATING PANEL | LEC- UPPER RIGHT |
| 17. | 76067489 | [1] | INSULATING PANEL | LEC- SIDE LEFT |
| 18. | 76067490 | [1] | INSULATING PANEL | LEC- SIDE RIGHT |
| 19. | 76067491 | [1] | INSULATING PANEL | LEC |
| 20. | 76067496 | [1] | INSULATING PANEL | LEC- UPPER LEFT |
| 21. | 76067497 | [1] | INSULATING PANEL | LEC- UPPER RIGHT |
| 22. | 76067498 | [1] | INSULATING PANEL | LEC- OUTER REAR |
| 23. | 76067499 | [1] | INSULATING PANEL | LEC- INNER REAR |
| 24. | 76067500 | [1] | INSULATING PANEL | LEC- INNER REAR |
| 25. | 76067506 | [1] | INSULATING PANEL | LEC- DASHBOARD |
| 26. | 76067535 | [1] | INSULATING PANEL | LEC- OUTER RIGHT |
