纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.652[25]) - ROPS CAB - HEATER - OPTIONAL CODE 76069709 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
651 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76067475 | [1] | AIR CONDITIONER | LECAIR CONDITIONING - ASSY SEE PAG.26 Superseded by part number: 76093962 |
| 2. | 11107231 | [4] | SCREW,Hex, M10 x 50mm, Cl 10.9 | LEC Superseded by part number: 75205092, 43249 |
| 3. | 11701714 | [4] | NUT | LEC Superseded by part number: 17038131 |
| 4. | 79109014 | [4] | PAD | LEC- UPPER |
| 5. | 76067743 | [4] | WASHER,M10 | LEC |
| 6. | 79109011 | [4] | PAD | LEC- LOWER |
| 7. | 76043653 | [3] | KNOB | LEC |
| 8. | 76045509 | [2] | GROMMET | LEC |
| 9. | 76043953 | [2] | DOWEL | LEC60-80 Superseded by part number: 13795820 |
| 10. | 76067473 | [1] | BEZEL | LEC- CONTROLS |
| 11. | 76043560 | [4] | THREADED INSERT,M4 | LEC |
| 12. | 15688001 | [1] | SELF-TAP SCREW,Cross Pan Hd, M4.2 x 13mm | JES |
| 14. | 76067476 | [1] | FLEXIBLE CONTROL | LEC- HOT WATER VALVE CONTROL |
| 15. | 76069329 | [6] | DIFFUSER | LEC |
| 16. | 71485276 | [1] | SPRING NUT | LEC |
| 17. | 71404503 | [2] | HOSE CLAMP,69.6mm - 77mm | LEC60-80 |
| 18. | 76067744 | [1] | PLUG | LEC12 |
| 19. | 71480911 | [4] | DUST CAP | LEC |
