纽荷兰零件查询(DC180LT) - CRAWLER DOZER (5/00-) (9.652[26]) - AIR CONDITIONING - HEATER - OPTIONAL CODE 76069709 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
315 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76027756 | [1] | FAN | LEC Superseded by part number: 76093954 |
| 2. | 14304221 | [5] | HEX SOC SCREW,M5 x 16mm, Cl 8.8, Full Thd | LEC Superseded by part number: 14304220 |
| 3. | 10902221 | [8] | BOLT,Hex, M6 x 16mm, CL 8.8 | BHB Superseded by part number: |
| 4. | 10977821 | [10] | BOLT,M5 x 19.65mm OAL, Cl 8.8 | IMO Superseded by part number: 75226650, 86050276 |
| 5. | 10571479 | [12] | LOCK WASHER,M5 | LEC Superseded by part number: |
| 6. | 14496321 | [10] | WASHER | LEC5,3 |
| 7. | 76035694 | [1] | HYDRAULIC VALVE | LEC |
| 8. | 14197890 | [10] | NUT | LEC5X1,8 Superseded by part number: 14197894 |
| 9. | 79096053 | [1] | RADIATOR, HEATER | LECCORE, A.C. |
| 10. | 14194090 | [8] | NUT,M6 x 1, Cage | TTF6X1,2 |
| 11. | 79096054 | [1] | THERMOSTAT | LEC Superseded by part number: 9972057 |
| 12. | 79096051 | [1] | CORE | LECHEATER |
| 13. | 10516479 | [8] | LOCK WASHER | BHB6,1X1,8 Superseded by part number: 10516471 |
| 14. | 10519421 | [8] | WASHER,6.4mm ID x 11.95mm OD x 1.6mm Thk | TTF Superseded by part number: 17094724 |
| 15. | 10396280 | [2] | GROMMET | LEC10X22 |
| 16. | 15896421 | [2] | NUT,M5, Cl 10 | TTF Superseded by part number: 1112803 |
| 17. | 79089649 | [1] | DRAINCOCK/TAP SUPPLY | LEC |
| 18. | 79083842 | [2] | HOSE CLAMP,M16-27 | LEC Superseded by part number: 18088392 |
| 19. | 79107290 | [1] | BRACKET | LEC |
| 20. | 79107291 | [1] | LEVER | LEC |
| 21. | 79102898 | [1] | SLEEVE | LEC Superseded by part number: 9968965 |
