| 1. |
65711
|
[2] |
SPRING
|
NH
Compression, 2-7/8" L
|
| 2. |
86637226
|
[2] |
TUBE
|
NH
Superseded by part number: 86900269
|
| 3. |
86636767
|
[1] |
TUBE,21.30 mm OD x 627.80 mm L
|
NH
|
| 4. |
86637221
|
[2] |
PLUG
|
NH
|
| 5. |
618883
|
[1] |
BALL JOINT HEAD,1/2" - 20
|
NH
End, Spherical Bearing, LH-Thread
|
| 6. |
614445
|
[1] |
SPHERICAL BEARING,12.764 mm ID x 33.34 mm OD x 15.88 mm
|
NH
End, Spherical Bearing, RH-Thread
|
| 7. |
614-8020
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 8. |
425-105
|
[8] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 9. |
614-10025
|
[5] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 11106231
|
| 10. |
495-11053
|
[4] |
WASHER,1/2", SAE
|
CAS
Superseded by part number: 87364, 72187259
|
| 11. |
229538
|
[4] |
U-BOLT
|
PA
G2, 5/16"-18 x 1-7/8"
|
| 12. |
825-51410
|
[1] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 13. |
832-46412
|
[2] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 14. |
11787
|
[1] |
FITTING,3/8"-24 Fem x 1/8" NPT
|
NH
Includes: 13362 Sleeve & 13367 Nut Superseded by part number: 84341119, 84341119, 87426476
|
| 15. |
86636636
|
[1] |
COLLAR
|
NH
Eccentric
|
| 16. |
232-4148
|
[1] |
NUT,1/2"-13, GC
|
CAS
Superseded by part number: 86992215
|
| 17. |
219-87
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 18. |
86637241
|
[1] |
BRACKET
|
NH
|
| 19. |
485-13116
|
[1] |
SET SCREW,Sq Hd, 5/16"-18 x 1", Cup pt
|
CAS
Superseded by part number: 88971
|
| 20. |
492-11031
|
[1] |
LOCK WASHER,5/16"
|
CAS
Superseded by part number: 83990583
|
| 21. |
495-11034
|
[9] |
WASHER,5/16", SAE
|
CAS
Superseded by part number: 83918746, 72187257
|
| 22. |
86636677
|
[2] |
GEAR
|
NH
Drive
|
| 23. |
425-145
|
[1] |
JAM NUT,Jam, 5/16"-18, G5
|
CAS
Superseded by part number: 86637931
|
| 24. |
673
|
[1] |
WASHER,29mm ID x 41mm OD x 1.52mm Thk
|
NH
|
| 25. |
86542822
|
[1] |
SET SCREW,Sq Hd, 5/16"-18 x 1 1/4", Cup Pt
|
NH
|
| 26. |
86633030
|
[1] |
SUPPORT
|
NH
|
| 27. |
86636900
|
[1] |
SPACER
|
NH
|
| 28. |
614-12040
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 29. |
86559592
|
[1] |
SPRING,Extension, 0.99" OD x 6-1/4" L
|
NH
Extension
|
| 30. |
9846836
|
[2] |
PLASTIC-RUBBER TUBE,3.58mm ID x 1000mm L
|
NH
|
| 31. |
219-60
|
[2] |
LUBE NIPPLE,1/8" - 27 Female NPTF
|
CAS
Superseded by part number: 86050275
|
| 32. |
86636632
|
[1] |
SPRING
|
NH
|
| 33. |
86637018
|
[1] |
ARM
|
NH
|
| 34. |
603153
|
[1] |
PLUG
|
NH
|
| 35. |
280129
|
[2] |
NUT,1/4"-20
|
NH
|
| 36. |
413-468
|
[2] |
BOLT,Hex, 1/4" - 20 x 4-1/4", Gr 5
|
CAS
Superseded by part number: 280595
|
| 37. |
280436
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 2 1/4", Gr 5
|
NH
|
| 38. |
86637020
|
[1] |
ARM
|
NH
|
| 39. |
26129
|
[1] |
WASHER,25.8mm ID x 39.69mm OD x 0.99mm Thk
|
NH
|
| 40. |
100-11100
|
[1] |
SNAP RING,#100, Ext
|
CAS
Superseded by part number: 25121
|
| 41. |
126-24
|
[2] |
WOODRUFF KEY,#15, 1/4" x 1"
|
CAS
Superseded by part number: 47471
|
| 42. |
86636778
|
[1] |
PLATE
|
NH
LH
|
| 43. |
86636725
|
[1] |
REDUCER,3/8" - 16
|
NH
|
| 44. |
88616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1.50", Gr 5
|
NH
Tap
|
| 45. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 46. |
602505
|
[1] |
BALL
|
NH
|
| 47. |
495-11041
|
[1] |
WASHER,0.406" ID x 0.812" OD x 0.065" W
|
CAS
Superseded by part number: 87016
|
