| 1. |
86636775
|
[1] |
SUPPORT
|
NH
|
| 2. |
86636780
|
[1] |
BAR
|
NH
Flat
|
| 3. |
86637302
|
[1] |
ARM
|
NH
|
| 4. |
86636986
|
[1] |
SUPPORT
|
NH
|
| 5. |
86620938
|
[1] |
ANGLE
|
NH
|
| 6. |
811-8020
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 7. |
811-10030
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 8. |
825-5148
|
[6] |
SERRATED NUT,M8, Flg Ser
|
CAS
Superseded by part number: 86505868
|
| 9. |
614-8030
|
[5] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43128
|
| 10. |
492-11044
|
[6] |
LOCK WASHER,7/16"
|
CAS
Superseded by part number: 81547
|
| 11. |
825-1410
|
[4] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 12. |
25457
|
[2] |
SPACER
|
NH
|
| 13. |
614-10020
|
[14] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 14. |
825-51410
|
[13] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 15. |
495-21038
|
[3] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 16. |
721
|
[1] |
WASHER,13.5mm ID x 22.2mm OD x 1.36mm Thk
|
NH
Spacer, 7/8" OD Superseded by part number: 86622500
|
| 17. |
905-10025
|
[4] |
BOLT,Hex Flg, M10 x 25mm
|
CAS
Superseded by part number: 274251
|
| 18. |
832-46408
|
[2] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 19. |
814-12080
|
[1] |
BOLT,Hex, M12 x 1.75 x 80mm, Cl 8.8
|
CAS
Superseded by part number: 43158
|
| 20. |
219-87
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 21. |
36334
|
[1] |
GUIDE
|
NH
Superseded by part number: 86553579
|
| 22. |
832-46412
|
[2] |
NUT,M12 x 1.75, Cl 8
|
CAS
Superseded by part number: 100038
|
| 23. |
614-12040
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 86629541
|
| 24. |
86636776
|
[1] |
PIN
|
NH
|
| 25. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
Superseded by part number: 80755
|
