纽荷兰零件查询(DC180PS) - CRAWLER DOZER (11/00-) (1.200[02]) - UNIT TORQUE CONVERTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
492 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76040834 | [2] | IDLE SHAFT | LEC Superseded by part number: 76076805 |
| 2. | 79010927 | [2] | GEAR | LEC |
| 3. | 11067476 | [2] | SNAP RING,M26, Ext | LEC |
| 4. | 11061076 | [4] | SNAP RING,M62, Int | ZED Superseded by part number: 370012 |
| 5. | 14460181 | [2] | O-RING,61.6mm ID x 2.62" Width | ZED Superseded by part number: 17284681 |
| 6. | 11067876 | [2] | SNAP RING,M30, Ext | TTF Superseded by part number: |
| 7. | 76040835 | [2] | RING | LEC- PUMP Superseded by part number: 76087545 |
| 8. | 20685450 | [4] | BALL BEARING,30 mm ID x 62 mm OD x 16 mm | TTF30X62X16 Superseded by part number: 75224976, 210064, 700803262 |
| 9. | 14458581 | [2] | O-RING,36.17mm ID x 2.62" Width | LEC |
