凯斯零件查询(RBX561) - CASE IH ROUND BALER (12/01-8/02) (047) - SCRAPER KIT, SERPENTINE ROLLERS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
336 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86618683
|
[1] |
SCRAPER
|
NH
Serpentine Rollers, Includes: Ref. 2 - 7
|
| 2. |
905-8020
|
[20] |
BOLT,Hex Flg, M8 x 20mm
|
CAS
Superseded by part number: 86511479
|
| 3. |
86637004
|
[2] |
SCRAPER BLADE
|
NH
|
| 4. |
87010760
|
[2] |
ANGLE
|
PA
|
| 5. |
140045
|
[8] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 6. |
614-10020
|
[8] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 7. |
86637019
|
[2] |
SUPPORT
|
NH
|
