纽荷兰零件查询(DC180PS) - CRAWLER DOZER (11/00-) (1.211[23]) - TRANSMISSION - COMPONENTS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
454 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 581371 | [1] | THRUST PLATE | LEC |
| 2. | 590537 | [1] | GEAR | LEC54T |
| 3. | 4951301 | [1] | NUT | LEC Superseded by part number: 5119147 |
| 4. | 4960759 | [1] | FLANGE | LEC |
| 5. | 4962194 | [1] | SPACER | LEC |
| 6. | 4985508 | [1] | GEAR | LEC54T |
| 7. | 11071376 | [1] | SNAP RING,M90, Ext | LEC Superseded by part number: 300639 |
| 8. | 11071876 | [1] | SNAP RING,M100, Ext | LEC Superseded by part number: 370010 |
| 10. | 14463881 | [2] | O-RING,1.359" ID x 0.139" Width | IMO Superseded by part number: 17289281 |
| 11. | 14465481 | [1] | O-RING,3.234" ID x 3.512" OD x 0.139" | LEC(M82.14 ID x 3.53 Thk) |
| 12. | 14496631 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 13. | 15970731 | [2] | BOLT,Hex, M10 x 1.25 x 25mm, Cl 10.9, Full Thd | LEC |
| 14. | 20943310 | [1] | BALL BEARING,40mm ID x 90mm OD x 23mm W | TTF40X90X23 |
| 15. | 86516079 | [2] | BALL BEARING,50mm ID x 80mm OD x 16mm W | NH50X80X16 |
| 16. | 28996360 | [1] | BALL BEARING,60mm ID x 110mm OD x 22mm W | LEC60X110X22 |
| 17. | 40000110 | [1] | SEAL | LEC35X62X10 Superseded by part number: 40000111 |
| 18. | 76027781 | [1] | IDLE SHAFT | LECASSY Superseded by part number: 79032465, 76028621 |
| 19. | 79086720 | [2] | SEAL,Split, 17mm ID x 19.8mm OD x 1.57mm Thk | LEC- IN ALTERNATIVE |
| 19. | 79051013 | [2] | SEAL,20.168mm OD x 1.143mm Width | LEC- IN ALTERNATIVE Superseded by part number: 79086720 |
| 20. | 79060757 | [1] | PIN,19.8mm OD x 98mm L | LEC |
| 21. | 76027777 | [1] | BUSHING,20.03mm ID x 26mm OD x 27mm L | LEC |
| 9. | 14457281 | [2] | O-RING,0.612" ID x 0.103" Width | TTF |
