现代零件查询R140LC-7 TRAVEL MOTOR(#2713-, 1/2, TYPE 1, LCM-7)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
436 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N5-40060
|
[1] |
TRAVEL MOTOR ASSY
|
|
| . |
31N5-40061
|
[1] |
TRAVEL MOTOR ASSY
|
|
| . |
31N5-40061BG
|
[1] |
TRAVEL MOTOR ASSY
|
|
| . |
31N5-40062BG
|
[1] |
TRAVEL MOTOR ASSY
|
|
| -2. |
XKAH-01067
|
[1] |
REAR FLANGE ASSY
|
|
| -21. |
XKAH-01075
|
[1] |
REAR FLANGE ASSY
|
|
| 201. |
XKAH-01069
|
[1] |
FLANGE-REAR
|
|
| 201. |
XKAH-00873
|
[1] |
FLANGE-REAR
|
|
| 201. |
XKAH-01682
|
[1] |
FLANGE-REAR
|
|
| 223. |
XKAH-00633
|
[1] |
SPOOL-MAIN
|
|
| -3. |
XKAH-00874
|
[2] |
STOPPER ASSY
|
|
| N294. |
XKAH-00875
|
[1] |
STOPPER-A
|
|
| N298. |
XKAH-00876
|
[1] |
STOPPER-B
|
|
| N295. |
XKAH-01052
|
[1] |
SPOOL
|
|
| N296. |
XKAH-01040
|
[1] |
SPRING
|
|
| 224. |
XKAH-00328
|
[2] |
PLUG
|
|
| 228. |
XKAH-00045
|
[2] |
SPRING
|
|
| 279. |
XKAH-00047
|
[2] |
O-RING
|
|
| 226. |
XKAH-00043
|
[2] |
PLUG
|
|
| 227. |
XKAH-00879
|
[2] |
VALVE-CHECK
|
|
| 230. |
XKAH-00046
|
[2] |
SPRING
|
|
| 234. |
XKAH-00048
|
[2] |
O-RING
|
|
| 221. |
XKAH-00032
|
[1] |
PLUG-PF
|
|
| 238. |
XKAH-00035
|
[1] |
O-RING
|
|
| 252. |
XKAH-00327
|
[4] |
PLUG-PT
|
|
| 244. |
XKAH-00880
|
[1] |
PLUG
|
|
| 268. |
XKAH-00056
|
[2] |
BALL-STEEL
|
|
| 242. |
XKAH-00411
|
[1] |
VALVE
|
|
| 272. |
XKAH-00462
|
[1] |
SEAT-VALVE
|
|
| 276. |
XKAH-00382
|
[1] |
RING
|
|
| 275. |
XKAH-00383
|
[1] |
SPRING
|
|
| 218. |
XKAH-00881
|
[1] |
SEAT-VALVE
|
|
| 219. |
XKAH-00392
|
[1] |
VALVE
|
|
| 220. |
XKAH-00391
|
[1] |
SPRING
|
|
| 222. |
XKAH-00390
|
[1] |
RING(FOR T-TYPE)
|
|
| 233. |
XKAH-00389
|
[1] |
O-RING
|
|
| 263. |
XKAH-00882
|
[1] |
SPOOL-2SPEED
|
|
| 263. |
XKAH-01683
|
[1] |
SPOOL-2SPEED
|
|
| 264. |
XKAH-00050
|
[1] |
PLUG-RO
|
|
| 264. |
XKAH-00050
|
[5] |
PLUG-RO
|
|
| 265. |
XKAH-00052
|
[3] |
O-RING
|
|
| 266. |
XKAH-01068
|
[1] |
SPRING-2 SPEED
|
|
| 267. |
XKAH-00884
|
[1] |
SCREW-SET
|
|
| 241. |
XKAH-00065
|
[2] |
PIN-PARALLEL
|
|
| 297. |
XKAH-00885
|
[1] |
ORIFICE
|
|
| 282. |
XKAH-00066
|
[9] |
BOLT-SOCKET
|
|
| 199. |
XKAH-01070
|
[1] |
NAME PLATE
|
|
| 199. |
XKAH-01434
|
[1] |
NAME PLATE
|
|
| 200. |
XKAH-00116
|
[2] |
SCREW-RIVET
|
|
| -4. |
XKAH-01065
|
[2] |
RELIEF VALVE ASSY
|
|
| -4. |
XKAH-01680
|
[2] |
RELIEF VALVE ASSY
|
|
| N301. |
XKAH-00888
|
[1] |
SEAT
|
|
| N301. |
XKAH-01066
|
[1] |
SEAT
|
|
| N302. |
XKAH-00889
|
[1] |
PLUNGER
|
|
| N302. |
XKAH-01064
|
[1] |
PLUNGER
|
|
| N303. |
XKAH-00667
|
[1] |
ROD
|
|
| N303. |
XKAH-01063
|
[1] |
ROD
|
|
| N304. |
XKAH-00668
|
[1] |
PISTON
|
|
| N305. |
XKAH-00670
|
[1] |
BODY
|
|
| N306. |
XKAH-00666
|
[1] |
PLUG
|
|
| N306. |
XKAH-01062
|
[1] |
PLUG
|
|
| 307. |
XKAH-00890
|
[1] |
SPRING
|
|
| N307. |
XKAH-00671
|
[1] |
SPRING
|
|
| N308. |
XKAH-00669
|
[1] |
SHIM
|
|
| 309. |
XKAH-00035
|
[1] |
O-RING
|
|
| 310. |
XKAH-00035
|
[1] |
O-RING
|
|
| 311. |
XKAH-00665
|
[1] |
RING-BACK UP
|
|
| K. |
XKAH-01074
|
[1] |
SEAL KIT
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
