| 1. |
87051671
|
[1] |
KIT
|
PA
2M Windguard Extension, Includes: Installation Instructions
|
| 2. |
86635755
|
[2] |
SPRING,15.88mm OD x 28.58mm L
|
NH
|
| 3. |
856964
|
[2] |
BUSHING
|
GI
Superseded by part number: 27695
|
| 4. |
87043776
|
[1] |
RETAINER
|
PA
|
| 5. |
87039915
|
[2] |
ARM
|
PA
|
| 6. |
87027237
|
[2] |
CHAIN,18 Links x 37.2mm = 670mm L
|
PA
Superseded by part number: 87055684
|
| 7. |
87046828
|
[1] |
PLATE
|
PA
|
| 8. |
87054717
|
[1] |
EXTENSION
|
PA
|
| 9. |
86603107
|
[2] |
NUT
|
PA
Square
|
| 10. |
87049395
|
[1] |
PLATE
|
PA
|
| 11. |
87043833
|
[1] |
WINDGUARD
|
NH
|
| 12. |
87038214
|
[1] |
RETAINER
|
PA
|
| 13. |
86619595
|
[2] |
DECAL
|
NH
Black & White Stripe
|
| 14. |
515-2195
|
[2] |
CLAMP,3/8", Insul, 1/4" Bolt
|
CAS
Superseded by part number: 86050346
|
| 15. |
614-6020
|
[2] |
BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120100
|
| 16. |
133095
|
[2] |
SPACER,10.32mm ID x 15.85mm OD x 7.9mm L
|
NH
|
| 17. |
811-10060
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 86512447
|
| 18. |
844-10030
|
[2] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 19. |
413-636
|
[2] |
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 88546, 72187212
|
| 20. |
811-6016
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 86512439
|
| 21. |
811-10040
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 374892
|
| 22. |
331175
|
[2] |
BOLT,Hex, M8 x 1.25 x 75mm, Cl 8.8
|
PA
Superseded by part number: Z1232960
|
| 23. |
825-2406
|
[5] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 24. |
825-2410
|
[4] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 25. |
825-1410
|
[2] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 26. |
832-46408
|
[2] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 27. |
832-46410
|
[2] |
NUT,M10 x 1.5, Cl 8
|
CAS
Superseded by part number: 100037
|
| 28. |
231-4146
|
[2] |
NUT,3/8"-16, GB
|
CAS
Superseded by part number: 88902
|
| 30. |
322357
|
[5] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 31. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 32. |
87362
|
[2] |
WASHER,5/16" SAE
|
NH
Superseded by part number: 83918746
|
| 33. |
495-21044
|
[2] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 34. |
495-21038
|
[4] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 35. |
48917
|
[2] |
WASHER
|
NH
|
| 36. |
87051682
|
[2] |
SPACER
|
PA
|
| 37. |
87043879
|
[2] |
RETAINER
|
PA
|
| 38. |
87051603
|
[1] |
FINGER
|
PA
LH
|
| 39. |
87051605
|
[4] |
FINGER
|
PA
Middle
|
| 40. |
87051604
|
[1] |
FINGER
|
PA
RH
|
| 41. |
86621502
|
[8] |
CLIP
|
NH
|
| 42. |
86622143
|
[2] |
SPRING
|
NH
|
| 43. |
86507486
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 44. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 45. |
825-1408
|
[2] |
NUT,M8, Cl 8
|
CAS
Superseded by part number: 43362
|
| 49. |
9706703
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
