| 1. |
86604848
|
[1] |
PTO
|
NH
540 RPM, Slip Clutch Superseded by part number: 87516693
|
| 2. |
86979217
|
[1] |
KIT
|
PA
Shield, Front Superseded by part number: 87552993
|
| 3. |
86979218
|
[1] |
KIT
|
PA
Shield, Rear Superseded by part number: 87552993
|
| 4. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Cone, Outer
|
| 7. |
86979196
|
[1] |
BEARING,86mm ID x 132mm OD x 12mm H
|
PA
|
| 8. |
86979199
|
[1] |
BEARING,95.5 mm ID x 115.5 mm OD x 33 mm
|
PA
|
| 10. |
86979215
|
[1] |
PTO SHAFT
|
PA
Front, 1-3/8", 6 Tooth Spline, 540 RPM Standard Superseded by part number: 87516693
|
| 10. |
87027319
|
[1] |
PTO
|
PA
Front, 1-3/8", 21 Spline, 1000 RPM Optional
|
| 10. |
87027320
|
[1] |
PTO
|
PA
Front, 1-3/4", 20 Spline, 1000 RPM Optional
|
| 11. |
86979205
|
[1] |
BELLEVILLE SPRING
|
PA
|
| 13. |
87018800
|
[1] |
KIT
|
PA
Ball Collar
|
| 14. |
86979188
|
[2] |
SPIDER,30.2mm Cap Dia, 92mm L, Grease-able
|
PA
Cross
|
| 15. |
86979189
|
[1] |
BODY
|
PA
|
| 16. |
86979202
|
[1] |
PIN
|
PA
Spring Superseded by part number: 14610770
|
| 17. |
86979192
|
[1] |
YOKE
|
PA
|
| 18. |
86979190
|
[1] |
TUBE,1070 mm L
|
PA
Drive
|
| 19. |
86979191
|
[1] |
YOKE,1110.50 mm L
|
PA
|
| 20. |
86979193
|
[1] |
SPIDER
|
PA
Superseded by part number: 84355352
|
| 21. |
86979216
|
[1] |
PTO SHAFT
|
PA
Rear Superseded by part number: 87516693
|
| 22. |
86979194
|
[1] |
CLUTCH
|
PA
Slip
|
| 24. |
86979197
|
[1] |
SHIELD
|
PA
|
| 25. |
87012736
|
[8] |
BOLT AND NUT
|
PA
Includes: Nut
|
| 26. |
87012758
|
[2] |
LUBE NIPPLE
|
PA
LUBRICATOR Superseded by part number: 84036369
|
| 27. |
PL
|
[17] |
PROCURE LOCALLY
|
BAS
Screw
|
| 28. |
86625865
|
[1] |
KIT
|
NH
Tapered
|
| 29. |
86979187
|
[1] |
YOKE
|
PA
Universal Joint, 1-3/8", 6 Tooth Spline, Standard, 540 RPM
|
| 29. |
86705060
|
[1] |
YOKE
|
GI
Universal Joint, 1-3/8", 21 Spline, Optional, 1000 RPM
|
| 29. |
86705059
|
[1] |
YOKE
|
PA
Universal Joint, 1-3/4", 20 Spline, Optional, 1000 RPM
|
| 30. |
86979198
|
[1] |
CHAIN,229mm L
|
PA
|
| 31. |
86979201
|
[1] |
YOKE
|
PA
|
| 32. |
86984909
|
[1] |
BUSHING
|
EML
Superseded by part number: 84026575
|
| 33. |
86625862
|
[2] |
DISC
|
NH
Superseded by part number: 86517364
|
| 34. |
86625863
|
[1] |
THRUST PLATE
|
NH
|
| 35. |
86625864
|
[1] |
HUB
|
NH
|
| 36. |
321204
|
[4] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 38. |
849471
|
[1] |
DANGER DECAL
|
NH
English
|
| 38. |
849482
|
[1] |
DANGER DECAL
|
NH
French
|
| 39. |
849472
|
[1] |
DANGER DECAL
|
NH
English
|
| 39. |
849483
|
[1] |
DANGER DECAL
|
NH
French
|
