纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (0.530[01B]) - MUFFLER - DC70 STD. S/N 13041068 & UP ; LGP S/N 13045016 & UP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
149 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76590716 | [10] | WASHER | MAC |
| 3. | 76607068 | [4] | SCREW | MAC Superseded by part number: 11106231 |
| 4. | 76595986 | [1] | EXHAUST SYSTEM PIPE | MACHOSE |
| 7. | 76607067 | [1] | SUPPORT | MAC |
| 8. | 76598726 | [1] | MUFFLER | MAC |
| 9. | 76595987 | [2] | CLAMP | MAC |
| 11. | 76598727 | [1] | ELBOW | MACTUBE with a 4-bolt flange mounted on exhaust manifold. Flange gasket Cummins # 3912220 |
| 12. | 76598238 | [1] | SUPPORT | MAC |
| 13. | 76607069 | [2] | SCREW | MAC Superseded by part number: 626-12035 |
| 14. | 76590728 | [4] | WASHER | MAC Superseded by part number: 895-11012 |
| 20. | 76590719 | [4] | SCREW | MAC Superseded by part number: 9706704 |
| 23. | 76598214 | [1] | FLEXIBLE HOSE | MACSLEEVE Superseded by part number: 76605856 |
| 24. | 76606982 | [2] | SCREW | MAC Superseded by part number: 9515003 |
| 25. | 76607070 | [2] | SCREW | MAC Superseded by part number: 43252 |
| 27. | 76590721 | [12] | LOCK WASHER | MACLOCKWASHER |
| 28. | 76590727 | [2] | WASHER | MACLOCKWASHER Superseded by part number: 412123 |
