纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (0.040[01]) - CRANKCASE DC70 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
878 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3933223 | [1] | CYLINDER HEAD | LCRANKCASE |
| 2. | 76191890 | [1] | BUSHING | TORBUSHING |
| 3. | 76191923 | [10] | SCREW | TORSCREW Superseded by part number: J904217 |
| 5. | 76191823 | [4] | PLUG | LECPLUG Superseded by part number: 75312133 |
| 6. | 76191834 | [2] | PLUG | TORPLUG |
| 7. | 76191882 | [3] | PLUG | TORPLUG Superseded by part number: J900956 |
| 8. | 76191869 | [10] | RING | TORDOWEL Superseded by part number: J900068 |
| 9. | 76191900 | [2] | BUSHING | TORDOWEL Superseded by part number: J902343AM |
| 10. | 76106568 | [4] | PLUG | LECNOZZLE |
| 12. | 75208120 | [2] | PIN | LECDOWEL |
| 14. | 75208135 | [2] | PLUG | LECPLUG Superseded by part number: J906619 |
| 15. | 76191749 | [1] | PLUG | LECPLUG Superseded by part number: J920706 |
| 16. | 3900687 | [1] | PLUG | LPLUG Superseded by part number: 41-3038 |
| 17. | 75286111 | [1] | PLUG | LECPLUG Superseded by part number: J900955 |
| 18. | 76191883 | [1] | PLUG | TORPLUG Superseded by part number: J900958 |
| 19. | 3904166 | [1] | ENGINE CYLINDER LINER | LECSLEEVE Superseded by part number: J904166 |
