纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (4.340[01A]) - SALT CHAIN- SHOES (L=400MM) DC70 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
998 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76598656 | [2] | SUPPORT | MACCarrier Roller |
| 2. | 76590728 | [4] | WASHER | MAC Superseded by part number: 895-11012 |
| 3. | 76590744 | [2] | NUT | MAC Superseded by part number: 12577521 |
| 4. | 76598657 | [2] | ROLLER | MACCarrier Roller |
| 5. | 76598658 | [8] | SCREW | MAC Superseded by part number: 9628065 |
| 6. | 76595963 | [8] | GASKET | MAC Superseded by part number: 76590727 |
| 8. | 76598659 | [2] | SCREW | CMI Superseded by part number: 86508581 |
| 9. | 76598660 | [4] | SCREW | MAC |
| 10. | 76598661 | [168] | SCREW | MACScrew, Pad Superseded by part number: 5117440 |
| 11. | 76598662 | [2] | TRACK LINK | MACMaster; One Side Of Link Only; Use With 76598663 |
| 12. | 76598663 | [2] | TRACK LINK | MACMaster; One Side Of Link Only; Use With 76598662 |
| 13. | 76598664 | [168] | NUT | MACNut, Pad Superseded by part number: 5117441 |
| 14. | 76598665 | [2] | KIT | MAC1 Kit per side Superseded by part number: 75128930, 76598729, 76598728, 75128929, 75128928 |
| 15. | 76598666 | [48] | SCREW | MAC Superseded by part number: 15215834 |
| 16. | 76605863 | [48] | LOCK WASHER | MAC Superseded by part number: 11198673 |
| 17. | 76598667 | [4] | TRACK ROLLER | MACRoller, Single Flange |
| 18. | 76598668 | [8] | TRACK ROLLER | MACRoller, Double Flange |
| 19. | 76598669 | [2] | IDLER WHEEL | MACSee Figure 4.346 01A |
| 20. | 76598272 | [32] | LOCK WASHER | MAC |
| 21. | 76605592 | [20] | SCREW | MAC Superseded by part number: 11119134 |
| 22. | 76598682 | [2] | DRIVING SPROCKET | MAC |
| 24. | 76598683 | [32] | SCREW | MAC |
| 25. | 76598684 | [1] | CHAIN | MACAssy Includes Links |
| 26. | 76598685 | [2] | TRACK ASSY | MACwith Pads Superseded by part number: 76598686, 76598684, 76598664, 76598661, 76598660 |
| 28. | 76598686 | [43] | TRACK SHOE | MACTrack Pads |
| 29. | 76605593 | [20] | LOCK WASHER | MAC Superseded by part number: 10517274 |
| 32. | 76598728 | [43] | PLUG | MACPin |
| 33. | 76598729 | [43] | SET OF RINGS | MACGRP |
