纽荷兰零件查询(DC70) - CRAWLER DOZER (N.A. VERSION) (4/99-) (3.440[01B]) - LIFT CYLINDERS PIPING - (ALL DC100'S) (DC80 - STD S/N 13141056 & UP) (DC70 - STD S/N 13041068 & UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
443 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76605870 | [4] | FLEXIBLE HOSE | MACHOSE |
| 1. | 76609663 | [4] | FLEXIBLE HOSE | MACHOSE |
| 1. | 76610160 | [4] | HOSE | MAC |
| 2. | 76590982 | [6] | HYD CONNECTOR | MACCONNECTOR |
| 3. | 76591176 | [2] | SCREW | MAC Superseded by part number: 7120024 |
| 4. | 76590895 | [2] | WASHER | MAC Superseded by part number: 86639313 |
| 5. | 76605871 | [2] | COLLAR | MACCLAMP |
| 6. | 76594898 | [1] | HYDRAULIC VALVE | MACELECTRO-VALVE ASSY - SEE FIG. 3.440 (02) |
| 10. | 76591003 | [1] | HYD CONNECTOR | MACCONNECTOR |
| 11. | 76591169 | [1] | HYD CONNECTOR | MACCONNECTOR |
| 12. | 76591181 | [3] | HYD CONNECTOR | MACCONNECTOR |
| 13. | 76591182 | [1] | HYD CONNECTOR | MACCONNECTOR |
| 14. | 76595872 | [1] | RIGID TUBE | MACTUBE |
| 15. | 76595873 | [1] | RIGID TUBE | MACTUBE |
| 20. | 76598640 | [1] | RIGID TUBE | MACTUBE |
| 21. | 76591190 | [1] | HYD. TUBE | MACTUBE |
| 22. | 76591191 | [2] | CHECK VALVE | MACVALVE |
| 23. | 76591192 | [2] | HYD CONNECTOR | MACCONNECTOR |
| 25. | 76591194 | [2] | HYD CONNECTOR | MACCONNECTOR |
| 26. | 76596045 | [4] | SEAL | MACO-RING |
| 27. | 76590848 | [2] | NUT | MAC Superseded by part number: 15503611 |
