现代零件查询R140LC-7A TRAVEL HYD PIPING 1(LCD-7A, TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
241 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 4. |
P950-127334
|
[4] |
HOSE ASSY-ORFS,FLG 0X45
|
|
| 5. |
P920-082035
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 6. |
P930-042043
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
X500-110003
|
[2] |
CONNECTOR-ORFS
|
|
| 8. |
X500-110001
|
[2] |
CONNECTOR-ORFS
|
|
| 9. |
X810-065151
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 10. |
X810-085353
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 11. |
S760-141421
|
[2] |
GROMMET
|
|
| 12. |
31E3-3118
|
[2] |
GROMMET
|
|
| 13. |
P173-120102
|
[8] |
FLANGE-HYD,SPLIT
|
|
| 14. |
Y171-019001
|
[4] |
O-RING
|
|
| 15. |
S621-014001
|
[4] |
O-RING
|
|
| 16. |
S631-011001
|
[3] |
O-RING
|
|
| 17. |
S017-16055D
|
[60] |
BOLT-HEX
|
|
| 18. |
S109-100306
|
[32] |
BOLT-SOCKET
|
|
| 20. |
S441-160006
|
[60] |
WASHER-HARDENED
|
|
| 21. |
S631-018001
|
[3] |
O-RING
|
|
| 22. |
S552-102370
|
[6] |
CLAMP-BAND
|
|
| 39. |
S631-014004
|
[8] |
O-RING
|
|
| 40. |
S621-011001
|
[4] |
O-RING
|
|
| 42. |
S631-021004
|
[4] |
O-RING
|
|
| 43. |
S621-018001
|
[4] |
O-RING
|
|
| 44. |
31Q4-41060
|
[2] |
ELBOW-15,LONG
|
|
| 45. |
31Q4-41050
|
[4] |
ELBOW-15,LONG
|
|
| 46. |
S631-011004
|
[2] |
O-RING
|
|
