现代零件查询R140LC-7A TRAVEL HYD PIPING 2(LCD-7A, TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
329 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 25. |
31N4-75110
|
[2] |
CHECK VALVE-PILOT
|
|
| 26. |
P913-087016
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 27. |
P913-087011
|
[5] |
HOSE ASSY-ORFS 0X0
|
|
| 28. |
P933-087010
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 29. |
X500-110012
|
[4] |
CONNECTOR-ORFS
|
|
| 30. |
31N4-41090
|
[2] |
CONNECTOR-ORIFICE
|
|
| 31. |
X520-110003
|
[2] |
ELBOW-90,ORFS
|
|
| 32. |
31N4-22160
|
[2] |
TEE-ORFS
|
|
| 33. |
S631-018004
|
[2] |
O-RING
|
|
| 34. |
32E6-10470
|
[2] |
GROMMET
|
|
| 35. |
S551-050203
|
[10] |
CLAMP-BAND
|
|
| 36. |
S015-080706
|
[6] |
BOLT-HEX
|
|
| 37. |
S411-080006
|
[6] |
WASHER-SPRING
|
|
| 38. |
X840-535353
|
[2] |
TEE-R/TYPE,SWIVEL,ORFS
|
|
| 39. |
S631-014004
|
[8] |
O-RING
|
|
| 41. |
S621-012001
|
[18] |
O-RING
|
|
