| 1. |
515-23190
|
[5] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86624005
|
| 2. |
413-628
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 72187210, 9706689
|
| 3. |
232-5316
|
[9] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 4. |
700718047
|
[1] |
HARNESS
|
CAS
- tail light
|
| 5. |
515-23444
|
[1] |
CLAMP,1 3/4", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 603022
|
| 6. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 7. |
825-1405
|
[4] |
NUT,M5, Cl 8
|
CAS
Superseded by part number: 10788811
|
| 8. |
515-25127
|
[9] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Superseded by part number: 86632595
|
| 9. |
700135935
|
[2] |
SUPPORT
|
HFI
BRACKET - light
|
| 10. |
700707095
|
[2] |
GROMMET
|
CAS
|
| 11. |
700716461
|
[2] |
TAIL LAMP
|
CAS
LIGHT - combination
|
| 12. |
409-7612
|
[6] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 13. |
515-2395
|
[4] |
CLAMP,3/8", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86572009
|
| 14. |
281-34912
|
[3] |
SELF-TAP SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHTCTS
|
| 15. |
700709354
|
[1] |
REPAIR KIT
|
IH
KIT - repair, harness (Includes items 16, 17 and 18) Superseded by part number: 87692802, 84286327, 225120C1
|
| 16. |
700708964
|
[1] |
WIRE CONNECTOR
|
CAS
CONNECTOR - shroud, 4 pin, male Superseded by part number: 87692802
|
| 17. |
700706401
|
[4] |
TERMINAL
|
CAS
PIN - male (18-20 Gauge) Superseded by part number: 225120C1
|
| 18. |
700706400
|
[4] |
PLUG
|
IH
SEAL (18-20 Gauge) Superseded by part number: 84286327
|
| 19. |
700717417
|
[1] |
LENS
|
CAS
- amber
|
| 20. |
700717386
|
[1] |
LENS
|
CAS
- red
|
| 21. |
700717381
|
[1] |
BULB
|
CAS
E 12V
|
| 22. |
700717385
|
[1] |
BULB
|
CAS
12V
|
