| 1. |
700711084
|
[1] |
BOLT
|
CAS
3/8-16 X 1-1/2 HFS GR8
|
| 2. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 3. |
413-636
|
[1] |
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 88546, 72187212
|
| 4. |
700135372
|
[1] |
SUPPORT
|
HFI
WA
|
| 5. |
M42297
|
[2] |
SPACER
|
IH
|
| 6. |
412-48
|
[2] |
CARRIAGE BOLT,Short Sq Nk 1/4" - 20 x 1/2", Gr 2
|
CAS
1/4-20 X 1/2 RHSNB Superseded by part number: 280700
|
| 7. |
1703354
|
[2] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 8. |
700150891
|
[1] |
PLATE
|
HFI
|
| 9. |
758342
|
[1] |
CABLE
|
CAS
- compression Superseded by part number: CAS758342
|
| 10. |
700135359
|
[1] |
PLATE
|
HFI
WA - left
|
| 11. |
700150892
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 12. |
413-1072
|
[2] |
BOLT,Hex, 5/8" - 11 x 4-1/2", Gr 5
|
CAS
Superseded by part number: 280183
|
| 13. |
230-41110
|
[2] |
LOCK NUT,5/8"-11, GA
|
CAS
5/8-11 HTLN GR/B Superseded by part number: 85700693
|
| 14. |
413-836
|
[2] |
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87975
|
| 15. |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 16. |
700715754
|
[1] |
JOINT
|
CAS
UNIVERSAL JOINT Superseded by part number: 700728184
|
| 17. |
413-624
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 18. |
700716093
|
[1] |
JACK
|
CAS
- assembly (Includes item 16) Superseded by part number: 87741929
|
| 19. |
435-7614
|
[2] |
GROOVED PIN,3/16" x 7/8", Type G
|
CAS
Pin, Grooved, 3/16" x 7/8", Type G
|
| 20. |
700135377
|
[1] |
SUPPORT
|
HFI
- left Superseded by part number: 700159597
|
| 21. |
700135374
|
[1] |
ANGLE
|
HFI
- right
|
| 22. |
6255350
|
[2] |
SPACER
|
CAS
|
| 23. |
700135378
|
[1] |
SUPPORT
|
HFI
- right
|
| 24. |
700135868
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 25. |
413-1048
|
[8] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
Superseded by part number: 87338
|
| 26. |
492-11062
|
[8] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 27. |
425-1010
|
[8] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 28. |
396-21066
|
[2] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 29. |
700135360
|
[1] |
PLATE
|
HFI
WA - right
|
| 30. |
700132293
|
[2] |
TUBE,38.1 mm OD, 66 mm Length
|
HFI
- roller Superseded by part number: 700155971
|
| 31. |
6250351
|
[2] |
SPACER
|
HFI
|
| 32. |
413-864
|
[2] |
BOLT,Hex, 1/2" - 13 x 4", Gr 5
|
CAS
1/2-13 X 4 C Superseded by part number: 86505993
|
| 33. |
230-4118
|
[2] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HTLN GR/B
|
| 34. |
700715760
|
[1] |
CRANK
|
CAS
- assembly (Includes items 19, 37, 38, 39 and 40)
|
| 35. |
700132317
|
[1] |
CRANK
|
CAS
ROD - crank Superseded by part number: 700715760
|
| 36. |
51200194
|
[1] |
RETAINER
|
CAS
RING - retaining
|
| 37. |
700715780
|
[1] |
HANDLE
|
CAS
Superseded by part number: 700715760
|
| 38. |
700132516
|
[1] |
TUBE
|
HFI
Superseded by part number: 700715760
|
