凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (7-08) - WHEEL, HUB AND AXLE ASSEMBLY, 11L X 15 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
G49041
|
[12] |
WHEEL NUT
|
CAS
9/16-18 WHEEL NUT
|
| 2. |
518842R1
|
[2] |
CAP
|
IH
HUB - cap
|
| 3. |
A57879
|
[2] |
RIM
|
CAS
WHEEL (11L X 15)
|
| 4. |
425-1312
|
[2] |
SLOTTED NUT,3/4"-16, G5
|
CAS
3/4-16 SHN GR 2 Superseded by part number: 88886
|
| 5. |
651818R91
|
[2] |
ROLLER BEARING,31.77 mm ID x 16.08 mm
|
IH
BEARING - cone, outer Superseded by part number: 84356153
|
| 6. |
700709830
|
[2] |
HUB
|
IH
(Includes items 7, 11 and 12)
|
| 7. |
826370
|
[2] |
BOLT,Ribbed Nk, 9/16" - 18 x 2.12"
|
CAS
9/16-18 X 2.12 BOLT, stud Superseded by part number: T57455
|
| 8. |
700135365
|
[2] |
SPINDLE
|
HFI
|
| 9. |
844050
|
[2] |
SEAL
|
L
|
| 10. |
663557R91
|
[2] |
BEARING ASSY,1.625" ID x 2.892" OD x 0.77"
|
IH
BEARING - cone, inner Superseded by part number: 86512015
|
| 11. |
663558R1
|
[2] |
BEARING CUP
|
IH
CUP - inner Superseded by part number: 86512015
|
| 12. |
651817R1
|
[2] |
BEARING CUP
|
IH
CUP - outer Superseded by part number: 84356153
|
| 13. |
26971
|
[2] |
WASHER
|
CAS
|
| 14. |
432-1024
|
[2] |
COTTER PIN,5/32" x 1 1/2"
|
CAS
5/32" x 1 1/2" Superseded by part number: 72187233, 88350
|
| 15. |
A38261
|
[2] |
VALVE
|
CAS
STEM Superseded by part number: 196033
|
