凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (7-22) - SHIELD, LATCH AND SUPPORT ASSEMBLIES, LEFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
846 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
440-13112
|
[18] |
SCREW,Cross Pan Hd, 5/16"-18 x 3/4"
|
CAS
5/16-18 X 3/4 CRPHMS GR60M Superseded by part number: 86511938
|
| 2. |
231-5145
|
[36] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 3. |
700150818
|
[1] |
SHIELD
|
HFI
- lower, left (Includes decals)
|
| 4. |
432-812
|
[3] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 5. |
700132503
|
[2] |
CHANNEL
|
HFI
|
| 6. |
495-61034
|
[2] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 7. |
754606
|
[2] |
SPRING
|
CAS
- compression
|
| 8. |
121-115
|
[18] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 9. |
700117061
|
[2] |
LATCH
|
CAS
|
| 10. |
700135650
|
[2] |
HANDLE
|
HFI
|
| 11. |
700135648
|
[2] |
PIN
|
HFI
WA
|
| 12. |
700135645
|
[1] |
SUPPORT
|
HFI
WA - lower, left
|
| 13. |
700135639
|
[1] |
SUPPORT
|
HFI
WA - upper, left
|
| 14. |
700135637
|
[1] |
SHIELD
|
HFI
- upper, left
|
| 15. |
700150819
|
[1] |
SHIELD
|
HFI
FRAME WA - left, shield (Includes reflector decals)
|
