| 1. |
232-5315
|
[11] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 2. |
121-115
|
[5] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 3. |
700150804
|
[1] |
SHIELD
|
HFI
- lower, right (Includes decal)
|
| 4. |
413-444
|
[4] |
BOLT,Hex, 1/4" - 20 x 2-3/4", Gr 5
|
CAS
1/4-20 X 2-3/4 C Superseded by part number: 72187194, 280566
|
| 5. |
496-11028
|
[4] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 6. |
232-4114
|
[4] |
LOCK NUT,1/4"-20, GC
|
CAS
1/4-20 HTLN GR B Superseded by part number: 280129
|
| 7. |
6549869
|
[4] |
SUPPORT
|
L
BRACKET - tension
|
| 8. |
7745003
|
[1] |
GUIDE
|
L
|
| 9. |
51200861
|
[1] |
U-BOLT
|
BRR
|
| 10. |
700707234
|
[1] |
BUTTON
|
IH
KNOB
|
| 11. |
413-620
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 12. |
232-5316
|
[7] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 13. |
700714888
|
[2] |
PULLEY
|
HFI
Superseded by part number: 700725038
|
| 14. |
700116106
|
[2] |
SPACER
|
HFI
|
| 15. |
700135802
|
[2] |
SUPPORT
|
HFI
GUIDE
|
| 16. |
121-108
|
[4] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 17. |
700107977
|
[3] |
GUIDE
|
CAS
- twine
|
| 18. |
409-7612
|
[3] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 19. |
700150807
|
[1] |
SHIELD
|
HFI
- upper, right (Includes decals)
|
| 20. |
413-548
|
[1] |
BOLT,Hex, 5/16" - 18 x 3", Gr 5
|
CAS
Superseded by part number: 88731
|
| 21. |
495-61034
|
[2] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 22. |
700115973
|
[3] |
SPACER
|
CAS
|
| 23. |
700132481
|
[1] |
SPACER
|
HFI
|
| 24. |
700135593
|
[1] |
LINK
|
HFI
|
| 25. |
700135953
|
[1] |
INDICATOR
|
HFI
|
| 26. |
700132479
|
[1] |
ANGLE
|
HFI
|
| 27. |
433-512
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 28. |
700150800
|
[1] |
SUPPORT
|
HFI
- switch
|
| 29. |
700707677
|
[1] |
SPRING
|
L
- compression
|
| 30. |
700135597
|
[1] |
SUPPORT
|
HFI
WA - upper
|
| 31. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
