凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (7-40) - MESH WRAP ROLLER SUPPORT ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
197 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T54573
|
[1] |
PIN
|
IH
.120 WIRE HAIR PIN COTTER Superseded by part number: 87421748
|
| 2. |
700148579
|
[1] |
ROD
|
HFI
- 4'
|
| 3. |
700148602
|
[1] |
PIVOT
|
HFI
WA - left
|
| 4. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 5. |
232-5316
|
[7] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
700148710
|
[1] |
PANEL
|
HFI
|
| 7. |
433-612
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 8. |
496-81010
|
[5] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 9. |
360-816
|
[4] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
1/2-13 X 1 HFS GR8 Superseded by part number: 87034823
|
| 10. |
231-5348
|
[6] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 11. |
700148603
|
[1] |
PIVOT
|
HFI
WA - right
|
| 12. |
700148597
|
[2] |
SUPPORT
|
HFI
WA
|
| 13. |
700148591
|
[1] |
ARM
|
HFI
WA
|
| 14. |
413-888
|
[2] |
BOLT,Hex, 1/2" - 13 x 5-1/2", Gr 5
|
CAS
.5 X 5.5 UNC GR5 YZD Superseded by part number: 88576
|
| 15. |
700711557
|
[2] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 16. |
700148688
|
[1] |
SHAFT
|
HFI
PIPE
|
| 17. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
