凯斯零件查询(RS451) - CASE IH ROUND BALER (1/99-12/00) (7-38) - MESH WRAP CARRIAGE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
463 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700148647
|
[2] |
PIN
|
HFI
|
| 2. |
700148646
|
[1] |
PANEL
|
HFI
|
| 3. |
700148633
|
[1] |
PANEL
|
HFI
WA
|
| 4. |
700148625
|
[1] |
ARM
|
HFI
WA
|
| 5. |
T54573
|
[3] |
PIN
|
IH
.120 WIRE HAIR PIN COTTER Superseded by part number: 87421748
|
| 6. |
440-13112
|
[8] |
SCREW,Cross Pan Hd, 5/16"-18 x 3/4"
|
CAS
5/16-18 X 3/4 CRPHMS GR60M Superseded by part number: 86511938
|
| 7. |
232-5315
|
[8] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 8. |
496-81010
|
[8] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 9. |
700148654
|
[1] |
TUBE,1344 mm Length
|
HFI
WA
|
| 10. |
700718297
|
[1] |
SHIELD
|
CAS
- hold down
|
| 11. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 12. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 13. |
700711134
|
[1] |
SCREW
|
CAS
3/8-16 X 1-3/4 HFS GR8
|
| 14. |
6869382
|
[1] |
SPACER
|
HFI
|
| 15. |
700148687
|
[1] |
PIN
|
HFI
|
| 16. |
700148713
|
[1] |
PANEL
|
HFI
|
| 17. |
700152042
|
[2] |
SPACER
|
HFI
|
