纽荷兰零件查询(DC75) - CRAWLER DOZER (8/04-) (09-40) - CAB - AIR CONDITIONING CONTROLS, COMPRESSOR AND DRYER LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
894 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76043653 | [1] | KNOB | LEC |
| 2. | 76049694 | [1] | SWITCH | LECAir Conditioning On/Off |
| 3. | 13795820 | [1] | INSERT | BURM4 x 14 Dowel Pin |
| 5. | 87414786 | [1] | FAN SWITCH | BURFan Speed Switch; Integral Part Of 87410122 Cab Main Harness |
| 7. | 76076702 | [1] | TUBE | LEC5/8 |
| 8. | 76076701 | [1] | TUBE | LEC3/4 |
| 9. | 76076703 | [1] | BRACKET | LEC |
| 10. | 10902424 | [1] | SCREW,Hex, M6 x 20mm, Cl 8.8, Full Thd | TTF Superseded by part number: |
| 11. | 76076721 | [1] | FLEXIBLE HOSE | LEC5/8 |
| 12. | 87329123 | [1] | HOSE | BUR3716 mm (146-1/4), Incl. 25; Replaces 87405602 hose; 3740 mm (147-1/4) |
| . . | 76035687 | [1] | RECEIVER-DRIER | LECDryer; Incl. Ref 13, 14 |
| 13. | 76035689 | [1] | FILTER | BUR Superseded by part number: 76035687 |
| 14. | 76035690 | [1] | SWITCH | LECValve |
| 15. | 79092065 | [1] | BRACKET | LEC |
| 16. | 16043624 | [2] | SCREW,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd | TTF |
| 17. | 12645034 | [4] | WASHER | BUR Superseded by part number: 86625263 |
| 18. | 87400727 | [1] | HOSE | BURIncludes (2) 128483A1 O-Rings |
| 19. | 87405603 | [1] | HOSE | BURIncl. 25, 26, 128485A1 fem end O-Ring, 76049689 male end O-Ring; Also Includes 1250594C1 Valve Core, 122553A1 Sealing Cap |
| 20. | 4982514 | [10] | CABLE TIE | LECClamp Superseded by part number: 87615202 |
| 21. | 87410122 | [1] | WIRE HARNESS | BUR |
| 22. | 418484A1 | [1] | WIRE HARNESS | BUR |
| 23. | 128483A1 | [4] | O-RING,1.78mm Thk x 7.65mm ID, -11, 70 Duro | IH |
| 25. | 128485A1 | [3] | O-RING,1.78mm Thk x 14mm ID, 70 Duro | IH Superseded by part number: 9827059 |
| 26. | 76049689 | [1] | O-RING,17.17mm ID x 1.78mm Width | LECO-ring To Expansion Valve |
| 27. | 87450713 | [2] | CONDUIT | BUR910 mm |
